ASHCROFT G17MEK15M1500#

B007ICA5L2

Ashcroft - G17MEK15M1500# - 7/16-20 SAE Male Pressure Transmitter 0 to 500 psi, 1 to 5VDC Output

Ashcroft - G17MEK15M1500# - 7/16-20 SAE Male Pressure Transmitter 0 to 500 psi, 1 to 5VDC Outputzoom

Attributes

Key Value
(hidden) connection bui.4-Pin Mini-DIN Hirschma.
Accuracy+/-0.5%
Accuracy - Transmitter+/-0.50% Full Scale
BrandASHCROFT
Burst Pressure10x Range
Calibration Certificate-
Compatible WithAny Process Compatible .
Country of OriginJapan
Country of Origin (subj.Japan
Electrical Connection4-Pin Mini-DIN Hirschma.
Electrical Connections4-Pin Mini-DIN Hirschma.
Electrical Connections .4 Pin Mini-DIN Connector
Enclosure RatingIP67 ; NEMA 4X
Explosion/Fire ProofNo
Features-
Fitting Material304 Stainless Steel
For Use With-
Full-Scale Accuracy?0.50% Full Scale
Housing304 Stainless Steel
Housing Material20% Glass Reinforced Ny.
IncludesInstructions
Intrinsically SafeNo
IP RatingIP67
ItemPressure Transmitter
Item?5LTE0
Loop Resistance-
Manufacturer Part NumberG17MEK15M1500#
Manufacturers Warranty .1 yr
Max. Pressure (PSI)1,000 psi
Maximum Operating Tempe.257 Degrees F, 257 ?F
Maximum Pressure500 psi
Mfr. Model?G17MEK15M1500#
Minimum Operating Tempe.-40 ?F, -40 Degrees F
Minimum Pressure0 psi
NEMA RatingNEMA 4X
Number of Wires3
Operating Temp.-40 to 257 F
Operating Temp. - Trans.-40 Degrees to 257 Deg.
Operating Temperature-40 Degrees F to 257 .
Output1 to 5V DC, 1 to 5VDC
Output - Transmitter1 to 5V DC
Overpressure2x Range
Power Required9 to 36V DC, 9 to 36VDC
Power Required - Transm.9 to 36V DC
Pressure Range0 psi to 500 psi
Pressure Unitspsi
Process Connection7/16-20 SAE Male, 7/16 .
Process Connection Gend.Male
Process Connection Size7/16 in
Process Connection Size.7/16"-20
Process Connection TypeSAE
Process Connection Type.SAE Male
Range0 to 500 psi
Range Units - Transmitt.psi
Range Values - Transmit.0 to 500
Response Time1 msec
SeriesG2
StandardsCE; CSA 222 6101-1; UL .
Storage Temperature Ran.-40 Degrees F to 257 De.
Thermal Error?3% (-4? to 185?F), +/-.
Transmitter TypePressure Transmitter
UNSPSC41112107
Wetted MaterialsStainless Steel, 304 St.
Wetted Materials - Tran.Stainless Steel
Wiring Entry1/2 in FNPT Conduit Con.
Wiring Entry - Transmit.1/2 in FNPT

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG0132142126.01In Stock26Ashcroft0.18126.0 @ 1
Grainger5LTE0189.751In StockASHCROFT189.75 @ 1
AmazonTPB007ICA5L2225.41In Stock5Ashcroft225.4 @ 1
