Unknown 5200 2RS/C3 PRX

B01LWVNED4

Angular Contact Ball Bearing, 850lb., NBR

Angular Contact Ball Bearing, 850lb., NBRzoom

Attributes

Key Value
ABEC Rating1
Ball MaterialAlloy Steel
Ball Material GradeAISI 52100
Bearing Industry Number5200
Bore Diameter10 mm
Bore Diameter Tolerance+/-0.008 mm
Cage MaterialPolyamide
ClosureDouble Sealed
Contact Bearing TypeAngular Contact
Dynamic Radial Load Cap.7,100 N
ItemAngular Contact Ball Be.
Load DirectionRadial, Thrust
Lubricant MaterialSRI 2 Grease, Polyrex E.
Matched Bearing TypeNot Matched/Single Bear.
Matched Mount TypeNot Applicable
Maximum Speed19,000 RPM
Maximum Temperature175 Degrees C
Minimum Temperature-40 Degrees C
Number of RowsTwo
Outside Diameter30 mm
Outside Diameter Tolera.+/-0.009 mm
Overall Width14.3 mm
Ring MaterialAlloy Steel
Ring Material GradeAISI 52100
Seal MaterialNitrile Rubber
Seal TypeContact
Shield MaterialNot Applicable
StandardsISO Certified 9001
Static Radial Load Capa.3,780 N
System of MeasurementMetric
