FAG Bearings 22324-E1A-MA-T41A

B00631MHHY

FAG 22324E1A-MA-T41A Shaker Screen Bearing, Straight Bore, Brass Cage, C4 Clearance, Metric, 120mm ID, 260mm OD, 86mm Width, 2600rpm Maximum Rotational Speed, 1160kN Static Load Capacity, 1080kN Dynamic Load Capacity

FAG 22324E1A-MA-T41A Shaker Screen Bearing, Straight Bore, Brass Cage, C4 Clearance, Metric, 120mm ID, 260mm OD, 86mm Width, 2600rpm Maximum Rotational Speed, 1160kN Static Load Capacity, 1080kN Dynamic Load Capacityzoom

Attributes

Key Value
Adapter Part NumberNot Applicable Inch | N.
Bore4.724 Inch | 120 Millim.
Bore ProfileStraight
BrandFAG BEARING
Cage MaterialBronze
CategorySpherical Roller Bearin.
EAN4026677848673
EnclosureOpen
Global Part Number GPN477199
Harmonized Tariff Code84823080
Inch - MetricMetric
Internal ClearanceC4-Extra Loose
Manufacturer NameSCHAEFFLER GROUP USA INC
Mounting MethodShaft Mount
Number of Rows of Rolle.Double Row
Outside Diameter10.236 Inch | 260 Milli.
price$ 1,773.54 / each
RelubricatableYes
Seal TypeOpen
title22324-E1A-MA-T41A
UNSPSC31171510
Weight / LBS48.28
Width3.386 Inch | 86 Millime.
Withdrawal NutNot Applicable
Withdrawal SleeveNot Applicable

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomLily Bearing22324-E1A-MA-T41A1507.511In StockFAG BEARING48.281507.51 @ 1
thumbzoomPurvis22324-E1A-MA-T41A1981.361In StockFAG1981.36 @ 1
