Harwin D2824-42

B008QY76VS

Harwin Socket Ic, Dil, 24Way, Tube 17 - D2824-42

Harwin Socket Ic, Dil, 24Way, Tube 17 - D2824-42zoom

Attributes

Key Value
Alternate Part No.855-D2824-42
Base Product NumberD2824
BrandHarwin
CategoryConnectors, Interconnec.
Contact Finish - MatingGold
Contact Finish - PostTin
Contact Finish Thicknes.Flash
Contact Finish Thicknes.196.9?in (5.00?m)
Contact Material - Mati.Beryllium Copper
Contact Material - PostBrass
Contact PlatingGold
Contact Resistance10mOhm
Current Rating (Amps)1 A
DescriptionCONN IC DIP SOCKET 24PO.
Detailed Description24 (2 x 12) Pos DIP, 0..
Digi-Key Part Number952-2214-ND
FeaturesOpen Frame
Housing MaterialPlastic
ManufacturerHarwin Inc., Harwin
Manufacturer Part No.D2824-42
Manufacturer Product Nu.D2824-42
Manufacturer Standard L.19 Weeks
Material Flammability R.UL94 V-0
MfrHarwin Inc.
Mounting StyleThrough Hole
Mounting TypeThrough Hole
Number of Positions24
Number of Positions or .24 (2 x 12)
Number of Rows2
Operating Temperature-55?C ~ 125?C
Operating Temperature R.- 55 C to + 125 C
PackageTube
Pitch2.54 mm
Pitch - Mating0.100" (2.54mm)
Pitch - Post0.100" (2.54mm)
ProductDIP / SIP Sockets
Product CategoryIC & Component Sockets
Product StatusActive
SeriesD2
TerminationSolder
Termination Post Length0.126" (3.20mm)
Termination StyleSolder Tail
TypeDIP, 0.6" (15.24mm) Row.

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomi-componentsD2824-420.691146366Harwin0.691 @ 10
HotendaH14898581.74110Harwin1.74 @ 10
thumbzoomZoroG5059118532.19321310Harwin2.19 @ 3213
thumbzoomDigi-Key37281792.5412536Harwin Inc.2.54 @ 10
thumbzoomswatee.comD2824-422.571135Harwin2.57 @ 10
thumbzoomNewark93K689332.821181HARWIN32.82 @ 10
