Molex 87264-1052

mpn0872641052
brandname: Molex
manufacturername: Molex

Molex Connector, Rcpt, 10Pos, 2Row, 2Mm - 87264-1052

Brand: Molex
PartNumber: 87264-1052
Manufacturer: Molex
Label: Molex

Attributes

Key	Value
Alternate Part No.	538-87264-1052
Amps - Plugs and Recept.	1 A
Angle	Right Angle
Applications	Automotive, General Pur.
Body Material - Pin and.	High Temperature Thermo.
Brand	Molex
Color	Black
Color - Plugs and Recep.	Black
Connector Type	Receptacle
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thicknes.	15.0?in (0.38?m)
Contact Finish Thicknes.	100.0?in (2.54?m)
Contact Gender	Socket (Female)
Contact Length - Post	0.100" (2.54mm)
Contact Material	Phosphor Bronze, -
Contact Plating	Gold
Contact Shape	Square
Contact Type	Female Socket
Current Rating	1 A
Current Rating (Amps)	1A
Family Name	Milli-Grid
Fastening Type	Push-Pull
Features	-
Housing Material	Thermoplastic
Ingress Protection	-
Insulation Color	Black
Insulation Height	0.157" (4.00mm)
Insulation Material	-
Manufacturer	Molex
Manufacturer Part No.	87264-1052
Mated Stacking Heights	-
Material Flammability R.	-
Mfr	Molex
Mounting Angle	Right
Mounting Type	Surface Mount Compatibl.
Number of Circuits	10
Number of Positions	10
Number of Positions Loa.	All
Number of Rows	2
Operating Temp. Range	-55? to +105?C
Operating Temperature	-55?C ~ 105?C
Packaging	Tube
Part # Aliases	0872641052
Part Status	Active
Pitch	2 mm
Pitch - Mating	0.079" (2.00mm)
Plating Material	Gold
Product Category	Headers & Wire Housings
Product Type	Headers - Socket
Row Spacing - Mating	0.079" (2.00mm)
Series	87264, 87264 Series
Standards	CSA LR19980, UL E29179
Style	Board to Board or Cable
Terminal Connection	Surface Mount
Termination	Solder
Termination Style	Through Hole
Tradename	Milli-Grid
Type	PCB Receptacle
Voltage	125V
Voltage Rating	125VAC, 125 V

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Preferred Tier
Waldom	MOLEX 87264-1052	1.33	52	157508		MOLEX	1.33 @ 52
jensentools.com	10197480	1.77	1	25		Molex	1.77 @ 25
Hotenda	H1418846	1.782	1	25		Molex	1.782 @ 25
us.rs-online.com	71466282	1.93	1	25		Molex Incorporated	1.93 @ 25
Component Electronics	SMT-21660	2.31	1	25		Molex	2.31 @ 25
Newark	02M6372	2.61	52	157092		MOLEX	2.61 @ 50
swatee.com	87264-1052	2.87	1	1180		Molex	2.87 @ 25
AmazonTP	B07QQCY9P4	68.54	1	25	1	Molex / Waldom	68.54 @ 25
AmazonSC	B07QZFMNVW	95.22	1	25		Molex	95.22 @ 25
Zoro	G2086950	163.8	1	25		Molex	163.8 @ 25
