- mpnTR-50222-12
- brandname: Macromatic
- manufacturername: Macromatic
MACROMATIC TR-50222-12 TIME-Delay Relay New in Box
- PackageQuantity: 1
- Manufacturer: MACROMATIC
- Label: MACROMATIC
Attributes
| Key | Value |
|---|
| AC Contact Rating - Rel. | 10 A @ 240V, 10A @ 240V |
| Adjustment Method - Tim. | Potentiometer |
| Adjustment Operator | Knob |
| Approvals | CE, CSA, cULus |
| Base Type | Octal |
| Base Type - Plug In Rel. | Octal |
| Body Depth | 2.9 in |
| Body Depth - Relay | 1.70 in, 1.7 in |
| Body Height | 1.7 in |
| Body Height - Relay | 2.9 in, 2.90 in |
| Body Width | 2.3 in |
| Body Width - Relay | 2.40 in, 2.4 in |
| Brand | Macromatic |
| Coil Volts | 120V AC/DC |
| Color | White |
| Contact Amp Rating (Res. | 10A |
| Contact Form - Relay | DPDT |
| Contact Material | Silver Nickel |
| Contact Rating (A) | 10 A |
| Contacts | DPDT |
| Current Stock | 47 |
| DC Contact Rating - Rel. | 10A @ 30V, 10 A @ 30V |
| Electrical Connection | Socket |
| Family Series | Macromatic Relays, TR-5. |
| Flat Pin Width | Not Applicable |
| Function - Timing Relay | On Delay |
| Gross Weight | 0 lbs |
| Hz - Electrical | 50 Hz, 60 Hz |
| International Shipping | No |
| Item - Relay | Single Function Timing . |
| Item Number | TR-50222-12 |
| Lead Time | Expected to ship in 1-2. |
| Manufacturer | Macromatic |
| Manufacturer Part Number | TR-50222-12 |
| Max Time | 300 s |
| Max. Time Setting - Tim. | 5 min |
| Min. Time Setting - Tim. | 3.00 sec, 3 sec |
| Mode of Operation | On Delay |
| Mounting - Relay | Plug In, Plug-In |
| Mounting Type | Socket |
| Mpn | TR-50222-12 |
| Multi-Function | No |
| Net Weight | 0 lbs |
| Nominal Coil Voltage | 120 VAC, 125 VDC |
| Number of Pins - Relay | 8 |
| Overall Depth | 3.5 in |
| Overall Height - Relay | 3.10 in, 3.1 in |
| Power Consumption - Rel. | 2 W, 2.5 VA, 2.5 VA, 2.. |
| Product Series | TR-5 |
| RoHS | Yes |
| SKU | ZO-G5234336 |
| Socket | 5X852, 1EGP3, 1EGP5 |
| Standards | UR, CSA, CE |
| Status Indicator | None |
| SubCategory | Electrical |
| Termination | 8 Pin |
| Time Range (Minutes) | 0-1, 0-2, 0-3, 0-5 |
| Time Range (Seconds) | 0-1, 0-2, 0-3, 0-5, 0-1. |
| Time Range Adjustment | Onboard |
| Timing Range | 3 |
| UPC | 801262043350 |
| Voltage (AC) | 120 VAC |
| Voltage (DC) | 120 VDC |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| grainger.ca | WWG23NU83 | 30.80320664 | 1 | In Stock | | MACROMATIC | 0.23 | 30.80320664 @ 1 |
 | Zoro | G5234336 | 32.62 | 1 | 80 | | Macromatic | 0.23 | 32.62 @ 1 |
 | Raptor Supplies | AB7KJX | 54.258516 | 1 | In Stock | | MACROMATIC | | 54.258516 @ 1 |
| Grainger | 23NU83 | 54.75 | 1 | 54 | 0 | MACROMATIC | | 54.75 @ 1 |
 | sustainablesupply.com | C1173761 | 55.05 | 1 | In Stock | | Macromatic | 0.23 | 55.05 @ 1 |
 | National Supply Network | 77981439 | 57.84 | 1 | In Stock | | Macromatic | | 57.84 @ 1 |
 | simsupply.com | ZO-G5234336 | 59.92 | 1 | 47 | | Macromatic | | 59.92 @ 1 |
 | bscsource.com | TR5022212 | 64.99 | 1 | In Stock | | Macromatic | | 64.99 @ 1 |
 | blackhawksupply.com | TR-50222-12 | 72.14 | 1 | In Stock | | Macromatic | | 72.14 @ 1 |
 | Walker Industrial | TR-50222-12 | 73.99 | 1 | In Stock | 10 | Macromatic | | 73.99 @ 1 |
 | Galco | TR-50222-12-MCRM | 81.6 | 1 | In Stock | | Macromatic | | 81.6 @ 1 |
| Newark | 48F5946 | 129.85 | 1 | In Stock | | MACROMATIC CONTROLS | | 129.85 @ 1 |
