Macromatic TR-50222-04

mpnTR-50222-04
brandname: Macromatic
manufacturername: Macromatic

Time Delay Relay,120VAC/DC,10A,DPDT,2VA

Brand: Macromatic
PartNumber: TR-50222-04
Model: TR-50222-04
PackageQuantity: 1
Binding: Misc.
Manufacturer: MACROMATIC
Label: MACROMATIC

Attributes

Key	Value
AC Contact Rating - Rel.	10 A @ 240V, 10A @ 240V
Adjustment Method - Tim.	Potentiometer
Adjustment Operator	Knob
Approvals	CE, CSA, cULus
Base Type - Plug In Rel.	Octal
Body Depth	2.9 in
Body Depth - Relay	1.70 in, 1.7 in
Body Height	1.7 in
Body Height - Relay	2.9 in, 2.90 in
Body Width	2.3 in
Body Width - Relay	2.40 in, 2.4 in
Brand	Macromatic
Coil Rating	2VA
Coil Volts	120V AC/DC
Color	White
Contact Amp Rating (Res.	10A
Contact Form - Relay	DPDT
Contact Material	Silver Nickel
Contact Rating (A)	10 A
Contacts	DPDT
Control Voltage	120
Current Rating	10 A
Current Stock	10
DC Contact Rating - Rel.	10A @ 30V, 10 A @ 30V
Electrical Connection	Socket
Family Series	Macromatic Relays, TR-5.
Flat Pin Width	Not Applicable
Function	On-Delay
Function - Timing Relay	On Delay
Gross Weight	0 lbs
Hz - Electrical	50 Hz, 60 Hz
International Shipping	No
Item - Relay	Single Function Timing .
Item Number	TR-50222-04
Manufacturer	Macromatic
Manufacturer Part Number	TR-50222-04
Max Time	5 s
Max. Time Setting - Tim.	5 sec
Min. Time Setting - Tim.	0.05 sec
Mode of Operation	On Delay
Mounting - Relay	Plug In, Plug-In
Mounting Type	Socket
Mpn	TR-50222-04
Multi-Function	No
Net Weight	0 lbs
Nominal Coil Voltage	120 VAC, 125 VDC
Number of Pins - Relay	8
Overall Depth	3.5 in
Overall Height - Relay	3.10 in, 3.1 in
Power Consumption - Rel.	2 W, 2.5 VA, 2.5 VA, 2..
Primary Type	Time Delay Relays
Product Series	TR-5
RoHS	Yes
Series	TR-5 Series
SKU	ZO-G5234311
Socket	5X852, 1EGP3, 1EGP5
Standards	UR, CSA, CE
Status Indicator	None
SubCategory	Electrical
Termination	8 Pin
Time Range (Seconds)	0-1, 0-2, 0-3, 0-5
Time Range Adjustment	Onboard
Timing Range	0, .05-5 SEC
UPC	801262043138
Voltage (AC)	120 VAC
Voltage (DC)	120 VDC

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
grainger.ca	WWG23NU78	30.80320664	1	In Stock		MACROMATIC	0.26	30.80320664 @ 1
Zoro	G5234311	44.95	1	47		Macromatic	0.26	44.95 @ 1
AmazonSC	B00HY15I8M	49.88	1	In Stock		Macromatic		49.88 @ 1
Raptor Supplies	AB7KJV	54.258516	1	In Stock		MACROMATIC		54.258516 @ 1
sustainablesupply.com	C1173757	55.05	1	In Stock		Macromatic	0.26	55.05 @ 1
simsupply.com	ZO-G5234311	59.17	1	10		Macromatic		59.17 @ 1
AmazonTP	B00HY15I8M	60.0	1	In Stock	2	MACROMATIC		60.0 @ 1
blackhawksupply.com	TR-50222-04	72.14	1	In Stock		Macromatic		72.14 @ 1
Walker Industrial	TR-50222-04	73.99	1	In Stock	17	Macromatic		73.99 @ 1
standardelectricsupply.com	2298965	77.08	1	In Stock		Macromatic Controls		77.08 @ 1
Galco	TR-50222-04-MCRM	81.6	1	In Stock		Macromatic		81.6 @ 1
us.rs-online.com	70175219	103.59	1	1		Macromatic		103.59 @ 1
Newark	48F5941	129.85	1	In Stock		MACROMATIC CONTROLS		129.85 @ 1
