Martin C442

B004BDNYHS

Martin C442 Spur Gear, 14.5? Pressure Angle, Cast Iron, Inch, 4 Pitch, 1-1/4" Bore, 11" OD, 2.000" Face Width, 42 Teeth

Martin C442 Spur Gear, 14.5? Pressure Angle, Cast Iron, Inch, 4 Pitch, 1-1/4" Bore, 11" OD, 2.000" Face Width, 42 Teethzoom

Attributes

Key Value
Bore Diameter1.25 in ; 31.8 mm
Bore TypeReboreable
Class6
Diametral Pitch4
External Length1.5" (38.1mm)
Face Width (In.)2
Gear TypeB1
Hub Dia. (In.)3.9845
Hub Outside Diameter3.9845" (101.2mm)
Hub Projection (In.)1.5
Hub StyleB
Length through Bore3.5
Length Through Bore3.5" (88.9mm)
MaterialCast Iron
Max. Bore2.5
Maximum Bore Diameter2.5" (63.5mm)
Min. Bore1.25
Number of Teeth42
Number Of Teeth42
Outer Diameter11" (279.4mm)
Outside Dia11.000"
Outside Dia. (In.)11
Pitch4
Pitch Dia. (In.)10.5
Pitch Diameter10.5" (266.7mm)
Pressure Angle14.5 Degrees PA
Pressure Angle (Deg.)14.5
Storage Height3.5
Storage Length11
Storage Width11
StyleB
UPC Code697950053929
Weight33.9 lbs. (15.4 kg), 33.
Width0 in

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomindustrialzone.comC442549.341In StockMartin1.0549.34 @ 1
us.rs-online.com72332473615.991In StockMartin Sprocket & Gear33.9615.99 @ 1
thumbzoomMRO Supply250829647.071In StockMartin Sprocket647.07 @ 1
thumbzoomZoroG3366591790.981In Stock14Martin Sprocket & Gear33.9790.98 @ 1
thumbzoomPurvisC442805.61In StockMartin805.6 @ 1
thumbzoommotionindustries.com00370824882.111In StockMartin882.11 @ 1
