- mpnLCD2/0-14A-X
- brandname: Panduit Corp
- manufacturername: Panduit Corp
Panduit LCD2/0-14A-X Code Conductor Copper Compression Lug, 2 Hole, 2/0 AWG, 1/4-Inch Stud, .63-Inch Hole Spacing
- Brand: Panduit
- PartNumber: LCD2/0-14A-X
- Model: LCD2/0-14A-X
- Color: Black
- Size: 1/4-Inch Stud Hole, .63-Inch Hole Spacing
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: Panduit
- Label: Panduit
Attributes
| Key | Value |
|---|
| Allowable Gauge Range | 2/0 |
| Approvals | CSA, UL |
| Base Product Number | LCD2 |
| Brand | Panduit, Pan-Lug? |
| Cable Size | 2/0 AWG |
| Catalog Number | LCD2/0-14A-X |
| Category | Connectors, Interconnec. |
| Color | Black |
| Color Code | Black |
| Color Family | Black |
| Connection Material | Tin |
| Connection Type | 1 x Terminal |
| Connector Type | Standard Barrel |
| Contact Finish | Electro-Tin |
| Contact Material | Copper |
| Country of Origin | MX - Mexico, Mexico |
| Country of Origin (subj. | Mexico |
| Description | CONN TERM RECT TONG 2/0. |
| Detailed Description | Terminal Connector Rect. |
| Diameter - Barrel ID | 0.450" (11.43mm) |
| Diameter - Barrel OD | 0.580" (14.73mm) |
| Diameter - Ring ID | 0.270" (6.86mm) |
| Die Color | Black |
| Digi-Key Part Number | 298-11806-ND |
| ECCN | EAR99 |
| Family Series | Panduit Terminals, Pan-. |
| Features | - |
| Finish | Tin-Plated |
| Gross Weight | 1.11 lbs |
| GTIN | 00074983383245 |
| Insulation | Non-Insulated |
| Item | Lug Compression Connect. |
| Item Number | LCD2/0-14A-X |
| Item Type | Copper Compression Conn. |
| Length | 2.7" |
| Length - Overall | 2.700" (68.58mm) |
| Made in USA | No |
| Manufacturer | Panduit Corp, Panduit |
| Manufacturer Part Number | LCD2/0-14A-X |
| Manufacturer Product Nu. | LCD2/0-14A-X |
| Manufacturer Standard L. | 2 Weeks |
| Material | Copper, Tin-Plated Copp. |
| Material/Composition | Copper |
| Max Conductor Range | 2/0 AWG |
| Mfr | Panduit Corp |
| Min Conductor Range | 2/0 AWG |
| Mounting | 42370, 2-Hole |
| Mounting Type | Free Hanging (In-Line) |
| Net Weight | 0 lbs |
| Number of Conductors | 1 |
| Number of Holes | 2 |
| Outer Diameter | 0.58 in. |
| Package | Bulk |
| Product Series | Pan-Lug Compression |
| Product Status | Active |
| RoHS Compliant | Yes |
| Series | Pan-Lug? |
| Size | 2/0 AWG Code |
| Special Features | Consult cable manufactu. |
| Standard | C22.2 No. 65-13, 486A-4. |
| Stud Hole Spacing | 0.63 in. |
| Stud Size | 1/4 in, 44565 |
| Stud/Tab Size | 1/4 Stud |
| Sub Brand | Pan-Lug |
| Tab Thickness | 0.130" (3.30mm) |
| Terminal Style | Two Stud Holes |
| Terminal Type | Rectangular Tongue |
| Termination | Crimp, Barrel |
| UNSPSC | 39121405 |
| UPC | 074983383245 |
| UPC Code | 074983383245 |
| Width | 0.85" |
| Width - Outer Edges | 0.850" (21.59mm) |
| Wire Gauge | 2/0 AWG |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | cbtcompany.com | LCD2/0-14A-X | 6.32 | 1 | In Stock | | PANDUIT | | 6.32 @ 1 |
 | alldataresource.com | PAN-LCD2/0-14A | 9.2 | 1 | In Stock | | Panduit | | 9.2 @ 1 |
 | Digi-Key | 4566176 | 11.38 | 1 | 3 | | Panduit Corp | | 11.38 @ 1 |
 | Zoro | G0777283 | 11.44 | 1 | In Stock | 58 | Panduit | 1.12 | 11.44 @ 1 |
| Radwell | LCD2014AX | 11.56 | 100 | In Stock | | PANDUIT | | 11.56 @ 100 |
 | Newark | 14AC0783 | 11.88 | 1 | In Stock | | PANDUIT | | 11.88 @ 1 |
| Onlinecomponents.com | LCD2/0-14A-X | 12.48 | 1 | 4 | | PANDUIT | | 12.48 @ 1 |
 | Galco | LCD2/0-14A-X-PNDT | 14.03 | 20 | In Stock | | Panduit | 1.11 | 14.03 @ 20 |
 | Platt.com | 0610930 | 14.93 | 1 | In Stock | | Panduit | | 14.93 @ 1 |
 | crescentelectric.com | 450478 | 15.97 | 1 | In Stock | | Panduit | | 15.97 @ 1 |
| Airline Hydraulics | PANDUIT LCD2/0-14A-X | 16.91 | 1 | In Stock | | Panduit Corp | | 16.91 @ 1 |
| us.rs-online.com | 70994565 | 17.8 | 10 | In Stock | | Panduit | | 17.8 @ 10 |
 | jensentools.com | 10016429 | 154.21 | 1 | In Stock | | Panduit | | 154.21 @ 1 |
 | gordonelectricsupply.com | LCD2/0-14A-X | 295.0 | 1 | In Stock | 12 | PANDUIT | | 295.0 @ 1 |
 | turtle.com | PAN LCD2/0-14A-X | 1653.67 | 1 | In Stock | | Panduit | | 1653.67 @ 1 |
| Graybar | 97280079 | 1849.9824 | 1 | In Stock | | Panduit | | 1849.9824 @ 1 |
