Jet GH-1440ZX LATHE 200S DRO & CC

mpn321501
brandname: Jet
manufacturername: Jet

JET GH-1440ZX, 14" x 40" Geared Head Metal Lathe, Collet Closer, ACU-RITE 200S DRO, 3-1/8" Spindle Bore, 3Ph 230/460V (321501)

Brand: Jet
PartNumber: GH-1440ZX LATHE 200S DRO & CC
Model: 321501
Color: Gray
PackageQuantity: 1
Binding: Tools & Home Improvement
Manufacturer: JET
Label: JET

Attributes

Key	Value
Accessories	Collet Closer </td
Accessory 2	Collet Closer </td
Bed Width	12 in
Carriage Travel (In.)	36-9/16 </td
Compound Slide Travel (.	5-1/8 </td
Condition	New
Cross Slide Travel (In.)	9 </td
Digital Readout	ACU-RITE 200S </td
Distance Between Centers	40 in
Distance Between Center.	40 </td
Drive	Geared Head </td
Features	Corner Radius Precision.
Follow Rest Capacity (I.	3/8 - 7 </td
Frequency	60 Hz
Gap Length	12 in
Horsepower	7 1/2 hp
Includes	10 in 3-jaw scroll chuc.
Item	Lathes
Length of Gap (In.)	12 </td
Machine Type	Engine lathe
Manufacturer	Jet
Max Tool Size (In.)	1 x 1 </td
Max. Cross Feed	0.0360 in
Max. Metric Thread	20 mm
Max. Spindle Speed	1,800 RPM
Min. Cross Feed	0.0006 in
Min. Metric Thread	0.05 mm
Min. Spindle Speed	42 RPM
Min. Threads per Inch	1 5/8
Motor (HP)	7-1/2 HP, 230/460V, 3Ph.
Number of Inch Threads	61, 61 </td
Number of Longitudinal .	122 </td
Number of Metric Threads	24, 24 </td
Number of Spindle Speeds	12 </td, 12
Overall Dimensions (L x.	96 x 44 x 66 </td
Overall Length	3-1/4 in
Phase	3
Prewired (V.)	230 </td
Range of Cross Feeds (I.	.0006 - .0365 </td
Range of Inch Threads (.	1-5/8 - 72 </td
Range of Longitudinal F.	.0015 - .0913 </td
Range of Metric Threads	.05 - 20 </td
Range of Spindle Speeds.	42 - 1,800 </td
Size	14 x 40 </td
SKU	321501
Spindle Bore	3 1/8 in
Spindle Bore (In.)	3-1/8 </td
Spindle Mount	D1-8 </td
Spindle Taper with Slee.	MT-7 (MT-5) </td
Steady Rest Capacity (I.	1/2 - 3-1/2 </td
Style (Type)	Engine - Large Spindle .
Swing Over Bed (In.)	14 </td
Swing Over Cross Slide .	7-5/8 </td
Swing Through Gap (In.)	23-5/8 </td
Tailstock Spindle Trave.	5 </td
Tailstock Taper	MT4
Taper in Tailstock Spin.	MT-4 </td
Voltage	230/460V
Weight (Lbs.)	5,187 </td
Width of Bed (In.)	13-3/8 </td

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
internationaltool.com	JET-321501	32149.0	1	In Stock		Jet		32149.0 @ 1
elitemetaltools.com	2323	34999.0	1	In Stock		JET		34999.0 @ 1
Global Industrial	WBB0230716	34999.0	1	In Stock	24	JET		34999.0 @ 1
JB Tools	JB-DS-WLT-321501	34999.0	1	In Stock		Jet		34999.0 @ 1
burnstools.com	321501	34999.0	1	In Stock		Jet		34999.0 @ 1
ToolUp.com	JET 321501	34999.0	1	In Stock		Jet		34999.0 @ 1
AceTool	JET-321501	34999.0	1	In Stock		Jet	5187.0	34999.0 @ 1
toolsplus.com	JET321501	34999.0	1	In Stock		JET		34999.0 @ 1
imsbolt.com	321501	34999.0	1	In Stock		JET		34999.0 @ 1
Zoro	G1939983	43919.99	1	In Stock		Jet		43919.99 @ 1
