Square D 8910DPA23V04

B00CONDCQA

Square D 8910DPA23V04 Dfinit Prpose Cntactr, 277Vac, 25A, 3P, Open

Square D 8910DPA23V04 Dfinit Prpose Cntactr, 277Vac, 25A, 3P, Openzoom

Attributes

Key Value
[Uc] Control Circuit Vo.277 V AC 60 Hz
[Ue] Rated Operational .600 V AC
ActionNon-Reversing
ApprovalsCSA, UL
China Rohs RegulationProduct out of China Ro.
Coil TypeMagnetic
Coil Voltage277 VAC
Coil Volts277V AC
ConditionNew
Contact Current Rating25 A
Control Voltage277 V
Country of Origin (subj.China
Depth3.12 in
DIN MountingYes
Electrical Connectionquick connect terminals.
Enclosure NEMA RatingNo Enclosure
Enclosure TypeOpen
Estimated Lead Time (in.8
Eu Rohs DirectiveCompliant
Family SeriesSquare D Contactors
Full Load Amps-Inductive25 A
Full Load Amps-Resistive30 A
Gross Weight0 lbs
GTIN785901024361
Height4 in
Horsepower Rating20 hp
HP @ 1 Phase - 120V2 hp
HP @ 1 Phase - 230V5
HP @ 1 Phase - 240V5 hp
HP @ 3 Phase - 230V10
HP @ 3 Phase - 240V10 hp
HP @ 3 Phase - 480V15 hp
HP @ 3 Phase - 575V10 hp
Hz50/60
IncludesQuick Connect Terminal
Inductive Current Rating25 A
ItemDefinite Purpose Magnet.
Item Number8910DPA23V04
Line Rated Current25 A
Locked Rotor 240/277V150 A
Locked Rotor 480V125 A
Locked Rotor 600V100 A
Locked Rotor Rated Curr.125 A 460 V AC || 100 A.
ManufacturerSquare D
Manufacturer Part Number155692
Max HP 120V 1PH2 hp
Max HP 230/240V 1PH5 hp
Max HP 230/240V 3PH10 hp
Max HP 460/480V 3PH15 hp
Max HP 575/600V 3PH20 hp
Maximum Horse Power Rat.2-2 hp 115 V AC, 1 phas.
Mercury FreeYes
Net Weight0 lbs
Nominal Coil Voltage277 VAC
Number of Poles3
Phase3 phase
Pole Contact Composition3 NO
Poles3 NO
Poles Description3P
Product CertificationsUL Recognized || CSA
Product Or Component Ty.Definite Purpose Contac.
Range Of ProductDPA
Reach RegulationReference contains Subs.
ReversingNo
Rohs Exemption Informat.Yes
Series8910DP Series, Standard
StandardsCE, CSA, UL, UL ; CSA ;.
TerminationBinder Head, Quick Conn.
UPC Code785901024361
Voltage Rating600 V
Warranty18 months
Weight2.000000
Width2.5 in

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomcappusa.com480991330.01In StockSquare D30.0 @ 1
thumbzoomGalco8910DPA23V04-SQD32.481In StockSquare D32.48 @ 1
thumbzoomindustrialrefrigerationparts.com8910DPA23V0434.061In StockSquare D2.034.06 @ 1
thumbzoomblackhawksupply.com8910DPA23V0439.361In StockSquare-D39.36 @ 1
thumbzoommidwestapplianceparts.com8910DPA23V04-SQ-P55.581In StockSquared55.58 @ 1
us.rs-online.com7058927279.571In StockSquare D79.57 @ 1
thumbzoomZoroG052237480.281In Stock26Square D0.9880.28 @ 1
Grainger5KAN685.751300SQUARE D85.75 @ 1
thumbzoomNational Supply Network5442172293.741In StockSquare D93.74 @ 1
thumbzoommayerelectric.comSQD8910DPA23V0495.751In StockSQUARE D95.75 @ 1
thumbzoomsustainablesupply.comC120545296.361In StockSquare D0.9896.36 @ 1
simplybreakers.com8910DPA23V04110.991In StockSchneider Electric110.99 @ 1
thumbzoomRaptor SuppliesAG7DKM139.34471851In StockSQUARE D139.3447185 @ 1
