Replaceable Drill Tip,PVD Carbide

<ul><li>Replaceable Drill Tip</li><li>Low Cutting Force Design Improves Hole Accuracy</li><li>Optimal Web Thickness Limits Deflection</li><li>Improved Hole Accuracy for Cast Iron Drilling</li><li>Superior Fracture Resistance</li></ul><p>Product Details:</p><ul><li>Insert Style: DA</li><li>Insert Size: 1550</li><li>Chipbreaker: M-KM</li><li>Insert Grade: PR1525</li><li>Material: Carbide</li><li>Coating Process: PVD</li><li>Coating / Composition: MEGACOAT NANO</li><li>[DC] Tip Cutting Diameter (Decimal Inch): 0.6102</li><li>[DC] Tip Cutting Diameter (mm): 15.50 </li><li>[k8] Dimension Tolerance (Decimal Inch): +0.0011, 0</li><li>[k8] Dimension Tolerance (mm): +0.027, 0</li><li>[PL] Point Length (Decimal Inch): 0.1358</li><li>[PL] Point Length (mm): 3.45</li><li>Insert Seat Size: 150</li><li>Insert Tip Angle (Degree): 140</li><li>Primary Workpiece Material: (K) Cast Iron</li><li>Insert Hand: Right-Hand</li><li>Insert Holding Method: Screw</li><li>Number of Cutting Edges: 2</li><li>Series: DRA Magic Drill</li><li>Application: Drilling</li><li>Compatible Holders (Partial): SS0625-DRA150M..., SF0750-DRA150M..., SS16-DRA150M..., SF20-DRA150M...</li></ul>DRA Magic Drill BrochureAutomotive Tooling Solutions Brochure
