Order GLBRC1000 by Dixon Valve 0 - 1000 PSI Filled Gauge, Center Back Mount - US Mega Store

2 1/2 BRSS CB 0-1000PSI Country of Origin: UNITED STATES NOTE: This is a special-order item; as such it is not returnable for any reason. Manufacturer warranties apply and cover the purchase in case of defect. Warranties are fulfilled directly by the manufacturer.This listing is for Each. 0 PSI MIN. PRESSURE 1000 PSI MAX. PRESSURE 0 MIN. PRESSURE IN PSI 1000 MAX. PRESSURE IN PSI CAST SOLID BRASS ENCLOSURE MATERIAL 1.5 PERCENT ACCURACY DIAL DISPLAY TYPE 0 TO 140 DEG F TEMPERATURE RATING 1/4 INCH END CONNECTION GLYCERIN FILLER MATERIAL 2-1/2 INCH DIAL DIAMETER CENTER REAR CONNECTION LOCATION ITEMS/FEATURES BRASS MOVEMENT WITH HIGHLY POLISHED BEARING SURFACE, POLISHED BRASS SLIP FIT RING WINDOW MATERIAL ACRYLIC WITH MEMBRANE ASSEMBLY MAXIMUM PRESSURE IN PSI - UOM PSI MINIMUM PRESSURE IN PSI - UOM PSI GLBRC1000 MODEL

<p><strong>Dixon Valve, GLBRC1000, 0 - 1000 PSI Brass Liquid Filled Gauge, Center Back Mount, 2-1/2"</strong></p><p><strong>Applications</strong></p><ul><li>All of the gauges supplied by Dixon are designed for long, reliable service under rugged conditions. Typical applications include those on pumps, hydraulic and pneumatic systems, compressors, machine tools and many other installations where it is necessary to have a gauge with a non-corrosive movement.</li></ul><p><strong>Specifications</strong></p><ul><li>2-1-2% accuracy</li><li>Figure interval: 300</li><li>Minor gradient: 20</li></ul><p><strong>Construction</strong></p><ul><li>Glycerin filled</li><li>Soild cast brass case with polished brass slip-fit ring</li><li>Acrylic window with membrane assembly</li><li>Copper alloy bourdon tube</li><li>Brass movement with highly polished bearing surfaces</li><li>Solid cast brass case with polished brass slip-fit ring</li></ul><p><strong>Safety notes</strong></p><ul><li>WARNING: This product contains a chemical known to the State of California to cause birth defects or other reproductive harm. Do not use in connection with drinking water. Wash hands after handling.</li></ul>
