Replaceable Drill Tip,PVD Carbide

<ul><li>Replaceable Drill Tip</li><li>Flat Bottom / Counterboring</li><li>Pilot Point Geometry and Double Margin for Improved Hole Accuracy</li><li>Reduced Burr Formation with Large Helix Angle and Corner Chamfer</li><li>Excellent Chip Evacuation with Large Groove and Cutting Edge Angle for Chip Thinning</li></ul><p>Product Details:</p><ul><li>Insert Style: DA</li><li>Insert Size: 1100</li><li>Chipbreaker: M-FTP</li><li>Insert Grade: PR1535</li><li>Material: Carbide</li><li>Coating Process: PVD</li><li>Coating / Composition: MEGACOAT NANO</li><li>[DC] Tip Cutting Diameter (Decimal Inch): 0.4331</li><li>[DC] Tip Cutting Diameter (mm): 11.00</li><li>[DC2] Cutting Diameter Secondary (Decimal Inch): 0.1339</li><li>[DC2] Cutting Diameter Secondary (mm): 3.40</li><li>[k8] Dimension Tolerance (Decimal Inch): +0.0011, 0</li><li>[k8] Dimension Tolerance (mm): +0.027, 0</li><li>[PL] Point Length (Decimal Inch): 0.0197</li><li>[PL] Point Length (mm): 0.50</li><li>Insert Seat Size: 110</li><li>Primary Workpiece Material: (P) Steel, (M) Stainless Steel</li><li>Insert Hand: Right-Hand</li><li>Insert Holding Method: Screw</li><li>Number of Cutting Edges: 2</li><li>Series: DRA Magic Drill</li><li>Application: Drilling</li><li>Compatible Holders (Partial): SS0500-DRA110M..., SF0625-DRA110M..., SS12-DRA110M..., SF16-DRA110M...</li></ul>DRA Magic Drill BrochureAutomotive Tooling Solutions Brochure
