Kyocera

<ul><li>Insert for External Turning, Copying, Boring</li><li>4 Cutting Edges</li><li>Heat-resistant MEGACOAT coating on cermet with excellent wear resistance</li><li>Application: High speed finishing of gray and nodular cast iron</li></ul><p>Product Details:</p><ul><li>Insert Style: DNGG</li><li>Insert Size: 431</li><li>Insert Grade: PV7005</li><li>Material: Cermet</li><li>Coating Process: PVD</li><li>Coating / Composition: TiC/TiN (MEGACOAT)</li><li>[IC] Inscribed Circle (Decimal Inch): 0.5000</li><li>[IC] Inscribed Circle (mm): 12.70</li><li>[S] Thickness (Decimal Inch): 0.1875</li><li>[S] Thickness (mm): 4.76</li><li>[RE] Corner Radius (Decimal Inch): 0.0156</li><li>[RE] Corner Radius (mm): 0.40</li><li>[D1] Hole Diameter (Decimal Inch): 0.2031</li><li>[D1] Hole Diameter (mm): 5.16</li><li>Rake: Negative</li><li>[AN] Relief Angle (Degree): 0</li><li>Included Angle (Degree): 55</li><li>Primary Workpiece Material: Cast Iron</li><li>Shape: Diamond</li><li>Insert Hand: Left-Hand</li><li>Insert Holding Method: Screw</li><li>Number of Cutting Edges: 4</li><li>Application: External Turning, Copying, Boring</li><li>Usage Classification: Continuous</li><li>Hole (Yes/No): Yes</li><li>Cutting Range: Medium</li><li>Compatible Holders (Partial): DDHNL...-1504, DDHNL...-1506, MDJNL...-12-4B, MDJNL...-16-4D, PDJNL...-16-4D, PDJNL...-15, PDJNL...-15U, PDHNL...-15, HA32PDUNR15-43, HA40PDUNR15-50, HA50PDUNR15-63, ...-DDUNR4, ...-DDUNR15-..., ...-PDUNR15-..., ...-PDQNR15-..., ...-PDZNL15-...</li></ul>
