Kaba Simplex Push Button Lockset,8000,Right,Lever R8148B-26D-41 ZO-G0490397 - SIM Supply

KABA Simplex / Eplex KABA Simplex / Eplex Kaba Simplex R8148B-26D-41 Lever Mechanical... Additional Information Manufacturer Kaba Access Control Model R8148B-26D-41 Dimensions Lock Body 7-3/8" H x 3-1/8" W x 3-3/16" D Number of Codes Single access code one easy to manage code for all users Programming Lock is easily programmed via keypad without removing lock from the door Handing R - Right Hand Operation Modes Combination Entry, Key Override (not supplied), Passage, Lockout, Deadbolt Numeric Keypad Vandal resistant, solid metal pushbuttons Backset 2 3â„4" (70 mm) Latch 3â„4" (19 mm) two-piece anti-friction latch; accommodates 1â„2" (13 mm) throw Minimum Stile Recommended 5" (127 mm) Interchangeable Cores Small format Best and equivalents (6 or 7-pin length). Less Core Door Preparation Easily installs on wood or metal doors. Standard (86) mortise preparation Door Thickness 1 3â„4" (44 mm) to 2 1â„4" (57 mm) Operating Temperature Highly weather resistant Certifications Americans with Disabilities Act (ADA) U.L. Listed 3-hour UL/ULC fire rating for "A" labeled doors Warranty 3-year warranty Weight 12.0000 R8148B-26D-41 Keyless Access
