Circuit breaker, PowerPact H, 50A, 3 pole, 600VAC, 14kA, I-Line, thermal magnetic, 80%, CBA | Mayer Electric

SQUARE D . SQDHDA360506

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerSQUARE D
Attribute00circuit breaker
Attribute01PowerPact H
Attribute02PowerPact
Attribute03distribution
Attribute0418 months
Attribute05I-Line bracket)
Attribute0650/60 Hz
Attribute07AL150HD
Attribute0825 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Attribute09thermal-magnetic
Attribute10163 mm
Attribute11690 V AC 50/60 Hz IEC 60947-3
Attribute125-5 N.m 2.5-6 mm? (AWG 14...AWG 10) || 14-14 N.m 10-95 mm? (AWG 8...AWG 3/0)
Attribute13bracket
Attribute14D
Attribute15850-850 A
Attribute16switched off (OFF) 1 trip indicator green)
Attribute172 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Attribute183t
Attribute19I-Line connection line || lugs load
Attribute204.5 in
Attribute212.2 kg
Attribute228 kV IEC 60947-2
Attribute23400 A
Attribute24toggle
Attribute2516 mm
Attribute26category A
Attribute2750-50 A
Attribute2880 %
Attribute2925 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
Attribute30750 V IEC 60947-2
Attribute31yes IEC 60947-2
Attribute32Modbus || Ethernet
Attribute333P
Attribute34, moq, multiple, tierMinQty11
Attribute35AWG 14...AWG 3/0 aluminium/copper terminal
Attribute36Black
Attribute37104 mm
Attribute3886 mm
Attribute39CBA
Attribute40, Attribute41, Attribute44Yes
Attribute42ENVPEP1311006EN
Attribute43Green Premium product
Attribute45Reference contains Substances of Very High Concern above the threshold
Attribute46DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Attribute47Product out of China RoHS scope. Substance declaration for your information.
Attribute48ENVEOLI1311006EN
Attribute49Compliant
Attribute50-2-70 ?C
Attribute51UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Attribute52UL || CSA || NOM
Attribute53front cover IP40 IEC 60529
Attribute543 IEC 60947-1
Attribute55-50-85 ?C
Attribute56CE
AttributeKey00Product Or Component Type
AttributeKey01Product Name
AttributeKey02Range
AttributeKey03Device Application
AttributeKey04Warranty
AttributeKey05Mounting Mode
AttributeKey06Network Frequency
AttributeKey07Terminal Identifier
AttributeKey08[Ics] Rated Service Breaking Capacity
AttributeKey09Trip Unit Technology
AttributeKey10, height_AttribHeight
AttributeKey11[Ue] Rated Operational Voltage
AttributeKey12Tightening Torque
AttributeKey13Mounting Support
AttributeKey14Breaking Capacity Code
AttributeKey15Magnetic Tripping Current
AttributeKey16Local Signalling
AttributeKey17Number Of Slots
AttributeKey18Protected Poles Description
AttributeKey19Electrical Connection
AttributeKey20Mounting Height
AttributeKey21, Weight_AttribNet Weight
AttributeKey22[Uimp] Rated Impulse Withstand Voltage
AttributeKey23Magnetic Hold Current
AttributeKey24Control Type
AttributeKey25Wire Stripping Length
AttributeKey26Utilisation Category
AttributeKey27Line Rated Current
AttributeKey28Continuous Current Rating
AttributeKey29Breaking Capacity
AttributeKey30[Ui] Rated Insulation Voltage
AttributeKey31Suitability For Isolation
AttributeKey32Communication Interface
AttributeKey33Poles Description
AttributeKey34Quantity Per Set
AttributeKey35Awg Gauge
AttributeKey36Color
AttributeKey37, width_AttribWidth
AttributeKey38, length_AttribDepth
AttributeKey39Phase Connection
AttributeKey40Rohs Exemption Information
AttributeKey41Mercury Free
AttributeKey42Environmental Disclosure
AttributeKey43Sustainable Offer Status
AttributeKey44Pvc Free
AttributeKey45Reach Regulation
AttributeKey46California Proposition 65 : WARNING: This product can expose you to chemicals including
AttributeKey47China Rohs Regulation
AttributeKey48Circularity Profile
AttributeKey49Eu Rohs Directive
AttributeKey50Ambient Air Temperature For Operation
AttributeKey51Standards
AttributeKey52Product Certifications
AttributeKey53Ip Degree Of Protection
AttributeKey54Pollution Degree
AttributeKey55Ambient Air Temperature For Storage
AttributeKey56Quality Labels
DimensionUnitmm
Extra Product NameCircuit breaker, PowerPact H, 50A, 3 pole, 600VAC, 14kA, I-Line, thermal magnetic, 80%, CBA | Mayer Electric
UPC, MPN, SKUSQDHDA360506
Weight2.2
WeightUnitkg
depth, length86.0
height163.0
jsonUrlData/Product/SQUARE-D-Circuit-breaker-PowerPact-H-I-Line-thermal-magnetic-50A-3-pole-14-kA-600-VAC-SQDHDA360506
jsonUrlData2c40ec7f6-e38a-41df-8aa9-ade40063fe7a
qtyInStock0
tierPrice1487.80
width104.0

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDHDA360506111 @ $487.80
