048A11O1239-Marathon Electric-AC
Gallery
Attributes
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Galco | 048A11O1239-MARA | 1 | 1 | 1 @ $283.50 | |
| Raptor Supplies | AG2YQY | 1 | 1 | ||
| 048A11O1239 | 1 | 1 | 1 @ $232.49 | ||
| Grainger | 32PF66 | 1 | 1 | ||
| G8796575 | 1 | 1 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
Marathon Electric/Regal Beloit - 048A11O1239-1/3 HP Direct Drive Blower Motor, Permanent Split Capacitor, 1075 Nameplate RPM, 208-230 Voltage
Brand: Marathon Electric
Listing
| Product group | BISS |
|---|---|
| Product type | ELECTRONIC_COMPONENT |
| Part number | 048A11O1239 |
| Items per pack | 1 |
| Label | Marathon Electric / Regal Beloit |
| Manufacturer | Marathon Electric / Regal Beloit |
Catalog
| Feature | Keep air circulating with this direct drive blower motor |
|---|---|
| Category | Tools & Home Improvement |
| MPN | 048A11O1239 |
| Product group | BISS |
| Product type | ELECTRONIC_COMPONENT |
| Manufacturer | Marathon Electric / Regal Beloit |
DDB Motor, PSC, OAO, 1/3 HP, 1075 RPM, 48Y
Brand: Marathon Industries
'Direct Drive Blower Motor, Permanent Split Capacitor Motor Type, Open Air-Over Enclosure, 1/3 HP, 1075 Nameplate RPM, Voltage 208-230, 3.0 Full Load Amps, 60 Hz, 1 Phase, 48Y Frame, Service Factor 1.0, Max. Ambient Temp. 40 Degrees C, Insulation Class B, Duty Continuous, Number of Speeds 1, Mounting Ring, Shaft Orientation Horizontal, Bearings Ball, Thermal Protection Auto, Rotation CCW, Nominal Efficiency 63.5 Percent, Body Dia. 5-5/8 In., Length Less Shaft 5-11/16 In., Overall Length 8-5/8 In.'
Details
- <b>Price For:</b> Each
Listing
| Product group | BISS Basic |
|---|---|
| Product type | ELECTRIC_MOTOR |
| Part number | 048A11O1239 |
| Items per pack | 1 |
| Label | MARATHON MOTORS |
| Manufacturer | MARATHON MOTORS |
Catalog
| Feature | <b>Price For:</b> Each |
|---|---|
| Category | Industrial & Scientific |
| MPN | 048A11O1239 |
| Product group | BISS |
| Product type | ELECTRONIC_COMPONENT |
| Manufacturer | MARATHON MOTORS |
Marathon Motors 1/3 HP Direct Drive Blower Motor, Permanent Split Capacitor, 1075 Nameplate RPM, 208-230 Voltage
Brand: CAI - MARATHON MOTORS
Keep air circulating with this direct drive blower motor. It features a permanent split capacitor motor design, and is suitable for use in direct-drive fans and blowers. It also features an open, air-over enclosure design, which mounts within the airflow of the fan to stay cool. Auto thermal protection allows the motor to start automatically after tripping.<br /><br /> Item: Direct Drive Blower Motor<br /> Motor Application: HVAC/R<br /> Motor Sub Application: Direct Drive Fan/Blower<br /> Motor Design: Permanent Split Capacitor<br /> Motor Enclosure Design: Open Air-Over<br /> HP: 1/3<br /> Nameplate RPM: 1075<br /> Voltage: 208-230<br /> Full Load Amps: 3.0<br /> Hz: 60<br /> Phase: 1<br /> Frame: 48Y<br /> Motor Service Factor: 1.00<br /> Max. Ambient Temp.: 40 Degrees C<br /> Ins. Class: B<br /> Duty: Continuous<br /> No. of Speeds: 1<br /> Motor Mounting Type: Ring<br /> Motor Mounting Position: Horizontal<br /> Motor Bearings: Ball<br /> Motor Thermal Protection: Auto<br /> Motor Shaft Rotation: CCWSE<br /> Nominal Efficiency: 63.5%<br /> Body Dia.: 5-5/8"<br /> Length Less Shaft: 5-11/16"<br /> Overall Length: 8-5/8"<br /> Shaft Dia.: 1/2"<br /> Shaft Length: 2-15/16"<br /> Motor Shaft Design: Double-Flat<br /> Capacitor Required: Included<br /> Resilient Ring Dia.: 2-1/4"<br /> Ring to Ring Center: 5-5/16"<br /> Stud Size: #8-32<br /> RPM Range: 1101-1200<br /> Standards: UL Recognized (E6312), CSA Certified (LR2025)<br /> Application: Blowers, Fans and Air Circulators<br /> Manufacturers Warranty Length: 1 yr.<br />
