Dorian Indexable Toolholder,MCLN,Alloy Steel 73310150124 ZO-G8405065 - SIM Supply
Gallery
Attributes
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| simsupply.com | ZO-G8405065 | 1 | 3 | 1 | 1 @ $99.93 |
| 73310150124 | 1 | -2 | 1 | 1 @ $76.74 | |
 Zoro | G8405065 | 1 | 9 | 1 | 1 @ $84.35 |
| AD4LVJ | 1 | 1 | 1 @ $101.33 | ||
| bhid.com | DORIAN 73310150124 | 1 | 1 | ||
 Amazon | B006ZOZULO | 1 | 1 | ||
 Grainger | 41T636 | 1 | 1 | 1 @ $88.00 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
Dorian Tool MCLN Square Shank Multi-Lock Turning Holder, Right Hand Cut, 1" Shank Width, 1" Shank Height, 5" Overall Length, 1/2" Insert
Brand: Dorian Tool
Details
- Maximum rigidity
- Utilizes lock pin and clamp
- Holds insert and seat secure for less vibration
- Style L - negative 5 degree end or side cutting edge angle for negative 80 degree diamond CNML 432 inserts
- Right hand cut
Listing
| Binding | Misc. |
|---|---|
| Product group | BISS Basic |
| Product type | CUTTING_TOOLS |
| Model | 73310150124 |
| Part number | MCLNR16-4C |
| Items per pack | 1 |
| Label | Dorian Tool |
| Manufacturer | Dorian Tool |
Dorian Tool - 73310150124 - Indexable Turning Toolholder, MCLN, Insert Style CNM., Overall Length 5
Brand: Dorian Tool
Technical Specification Item Indexable Turning Toolholder Toolholder Style MCLN Insert Style CNM. Insert Shape 80 Degrees Diamond Overall Length 5 Shank Width 1 Cutting Direction Right Hand Rake Negative ANSI Code MCLNR164C Cutting Application Turning Cutting Height 1 Features Hardened to 44 HRC Head Length 1-1/4 Insert Clearance Angle 0 Degrees Insert Holding Type Clamp and Lock Pin Insert Inscribed Circle 1/2 Insert Size 432 ISO Number MCLNR164C Shank Height 1 Shank Material Alloy Steel Side Cutting Edge Angle -5 Degrees This listing is for each. Item : Indexable Turning Toolholder Clamp Screw : XNS-48 Shim : ICSN-433 Shank : Square Insert Screw : NL-46 Rake : Negative Insert Shape : 80 Degrees Diamond Type : CNMG Holder Clamp : CL-20 Style : MCLNR16-4C Insert Size : 432 Cutting Direction : Right Hand Overall Length : 5 in ISO Number : MCLNR164C Head Length : 1-1/4 in Shank Material : Alloy Steel Insert Clearance Angle : 0 Degrees Features : Hardened to 44 HRC Cutting Application : Turning Shank Width : 1 in Cutting Height : 1 in Side Cutting Edge Angle : -5 Degrees ANSI Code : MCLNR164C Insert Style : CNM. Insert Holding Type : Clamp and Lock Pin Insert Inscribed Circle : 1/2 in Shank Height : 1 in Toolholder Style : MCLN Country of Origin (subject to change) : United States
Details
- Technical Specification Item Indexable Turning Toolholder Toolholder Style MCLN Insert Style CNM
Listing
| Product group | BISS Basic |
|---|---|
| Product type | MATERIAL_HANDLING |
| Part number | 73310150124 |
| Items per pack | 1 |
| Label | Dorian Tool |
| Manufacturer | Dorian Tool |
Catalog
| Feature | This turning toolholder features a multi-lock design |
|---|---|
| Category | Industrial & Scientific |
| MPN | 73310150124 |
| Product group | Single Detail Page Misc |
| Product type | MISC_OTHER |
| Manufacturer | Dorian Tool |
