ICN2P60SC35I-Philips Advance Transformer-Fluorescent

High Frequency Electronic Ballasts Type: Electronic High Frequency Start Method: Instant Start Voltage: 120 Type of Lamp: F72T12-55W, F96T12/ES -60W, F96T12-75W Number of Lamps: 2 Height: 1.5 In.

Sold as 2 UNITS at $26.95 per unit. (1 unit = each.) Electronic ballast for (1-2) F72T12, F96T12 or F96T12ES lamp. Approved for commercial applications. Instant start high power factor. Input voltage 120V. Input frequency 50/60 hertz. Ballast factor (2) light F96T12 .88, (2) lights F96T12/ES .88. Ballast efficacy factor (2) light F96T12 .65, (2) lights F96T12ES .84. Max. THD percent: 20%. Minimum start temperature F96T12 0 deg. F, F96T12/ES 60 deg. F. UL listed and CSA certified. Compatible with Sensormatic systems. Boxed. Manufacturer number: REL2P60SA35I. SKU #: 3249430. Country of origin: China. Distributed by Philips Lighting Electronics.

Philips Advance Centium Electronic fluorescent ballast is suitable to use with one/two 75-Watt F96T12 lamp. It has voltage rating of 120/277 Volts. Instant start ballast with 0.88 ballast factor, has ignition time of 0.1 sec. It features metal housing. Ballast accommodates solid wire of size 18 AWG. It offers 0.98 power factor. This ballast has parallel lamp connection. It operates at the frequency rating of 50 - 60 Hz. It measures 9.5 Inch x 1.7 Inch x 1.18 Inch. Ballast withstands temperature

The Energy Policy Act of 2005 (EPAct 2005) provides a tax deduction for commercial buildings for the certified use of qualifying energy-efficient technologies in both new construction and renovation applications. This act also closes the loop on existing Department of Energy regulations that prohibit the sale of T12 magnetic ballasts after July 2010. Philips Lighting Electronics is leading the way with a complete line of proven T12 electronic ballasts that are excellent replacement options for our industry-leading magnetic fluorescent ballasts. By converting Philips Advance T12 electronic ballasts today, oneyou can also enjoy the benefits of the same light output, quieter operation, improved efficiency (up to 30% more efficient than magnetic ballasts) and Energy Star compatibility. Lamp Name No. of Lamp Design Lamp Wattage Actual Lamp Wattage Input Voltage Voltage Type Lamp Starting Method Ballast Family Input Power Ansi (Watts) Ballast Factor Max. THD % Line Current (Amps) Ballast Life F72T12 (55W) 1 60 55 120 Dual IS Centium 68 1.05 10 0.70 50000 F72T12 (55W) 2 60 55 120 Dual IS Centium 108 0.92 10 0.91 50000 F72T12 (55W) 1 60 55 277 Dual IS Centium 67 1.05 10 0.31 50000 F72T12 (55W) 2 60 55 277 Dual IS Centium 107 0.92 10 0.40 50000 F96T12/ES (60W) 1 60 60 120 Dual IS Centium 70 1.04 10 0.53 50000 F96T12/ES (60W) 2 60 60 120 Dual IS Centium 105 0.89 10 0.88 50000 F96T12/ES (60W) 1 60 60 277 Dual IS Centium 38 1.04 10 0.24 50000 F96T12/ES (60W) 2 60 60 277 Dual IS Centium 103 0.89 10 0.38 50000 F96T12 (75W) 1 60 75 120 Dual IS Centium 84 1.04 10 0.55 50000 F96T12 (75W) 2 60 75 120 Dual IS Centium 137 0.90 10 1.17 50000 F96T12 (75W) 1 60 75 277 Dual IS Centium 82 1.04 10 0.25 50000 F96T12 (75W) 2 60 75 277 Dual IS Centium 135 0.90 10 0.50 50000
