Omron Automation . E2EX3D1M1G

[Cylinder type sensing head size]M12 <br />[Type]Shielded <br />[Sensing method]Inductive type <br />[Sensing distance]3mm -10% to +10% <br />[Setting distance]0 to 2.4 mm <br />[Differential distance]10% Max. of sensing distance <br />[Sensing object]Ferrous metal(Sensitivity lowers with non-ferrous metals.) <br />[Standard sensing object]Iron 12*12*1mm <br />[Response frequency]DC:1 kHz(average) <br />[Power supply voltage]12 to 24 VDC ripple(p-p):10% Max. <br />[Operating voltage range]10 to 30 VDC <br />[Leakage current]0.8 mA Max. <br />[Control output(Output type)]DC 2-wire models with polarity <br />[Control outpu(Switching capacity)]3 to 100mA <br />[Control outpu(Residual voltage)]3 V Max.(under load current with cable length of 2m) <br />[Indicator]Operation indicator(red), Operation setting indicator(green) <br />[Operation mode]NO <br />[Protective circuit]Surge suppressor,Output short-cut protection <br />[Ambient temperature]Operating:-25 to 70 CEL,Storage:-40 to 85CEL(with no icing or condensation) <br />[Ambient humidity]35 to 95 %RH(with no condensation) <br />[Temperature influence]+/- 10% Max. of sensing distance in temperature range of -25 to +70 CEL(As the basis for sensing distance of 23CEL) <br />[Voltage influence]+/- 1% Max. of sensing distance in rated voltage range +/- 15%.(As the basis for sensing distance at standard power voltage) <br />[Degree of protection]IEC60529:IP67 <br />[Applicable standard(EC Directive(Low Voltage Directive))]EN60947-1,EN60947-5-2 <br />[Applicable standard(EC Directive(EMC))]EMI:EN60947-5-2,Emission Enclosure:CISPR11 Group 1 class A,EMS:EN60947-5-2,Immunity ESD:IEC61000-4-2,Immunity RF-interference:IEC61000-4-3,Immunity Conducted Disturbance:IEC61000-4-6,Immunity Burst:IEC61000-4-4,CE marking:Equipped,Applicable standard(CCC mark)]Not equipped <br />[Connection method]M12 connector models <br />[Weight(Packed state)]approx. 25 g<br><br><br>(1)
