CCGT 21505 PV710 Grade PVD Cermet

<ul><li>Insert for External Turning, Facing, Boring, Internal Facing, Sub-Spindle</li><li>2 Cutting Edges</li><li>MEGACOAT NANO efficient machining with high quality surface finishes and superior wear and adhesion resistance</li><li>Application: Recommended cermet for long tool life and stable machining for high speed continuous cuts</li></ul><p>Product Details:</p><ul><li>Insert Style: CCGT</li><li>Insert Size: 21505</li><li>Insert Grade: PV710</li><li>Material: Cermet</li><li>Coating Process: PVD</li><li>Coating / Composition: TiCN (MEGACOAT NANO)</li><li>[IC] Inscribed Circle (Decimal Inch): 0.2500</li><li>[IC] Inscribed Circle (mm): 6.35</li><li>[S] Thickness (Decimal Inch): 0.0938</li><li>[S] Thickness (mm): 2.38</li><li>[RE] Corner Radius (Decimal Inch): 0.0079</li><li>[RE] Corner Radius (mm): 0.20</li><li>[D1] Hole Diameter (Decimal Inch): 0.1102</li><li>[D1] Hole Diameter (mm): 2.80</li><li>Rake: Positive</li><li>[AN] Relief Angle (Degree): 7</li><li>Included Angle (Degree): 80</li><li>Primary Workpiece Material: Steel</li><li>Secondary Workpiece Material: Stainless Steel</li><li>Shape: Diamond</li><li>Insert Hand: Neutral</li><li>Insert Holding Method: Screw</li><li>Number of Cutting Edges: 2</li><li>Application: External Turning, Facing, Boring, Internal Facing, Sub-Spindle</li><li>Usage Classification: Continuous</li><li>Hole (Yes/No): Yes</li><li>Cutting Range: Medium</li><li>Compatible Holders (Partial): ACLCR...-2JXFF, ACLCL...-2JXFF, ACLCR...-06FF, ACLCL...-06FF, SCLCR...-2…, SCLCL...-2…, SCLCR...-2JXFF, SCLCL...-2JXFF, SCLCR...-06…, SCLCL...-06…, S...SCLCL06, A...SCLCR2..., A...SCLCL2..., A...SCLCR06-..., A...SCLCL06-..., S...SCLCR06-..., S...SCLCL06-..., E...SCLCR2..., E...SCLCL2..., E...SCLCR06-..., E...SCLCL06-..., KSTBSR16/20CCET215</li></ul><p >TN610 / TN620 / PV710 / PV720 Brochure</p>
