TEC 864 108˚ Opening Wrap-Around Face Frame Hinge, 45mm Boring Pattern, Soft-Closing, 1-1/2
Gallery
Attributes
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Wurth | GTEC4549-15 | 1 | 1 | 1 @ $4.55 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
Rok Hardware Grass TEC 864 108 Degree 1-1/2" Overlay 3 Level Soft Close Screw On Compact Cabinet Hinge 04549A-15 3-Way Adjustment 45mm Screw Hole Pattern
Brand: Rok
MADE IN THE USA<br><br> ~Face Frame Hinge with integrated Soft-close<br> ~ No additional installation of the Soft-close is required.<br> A three tiered adjustment switch allows various levels of resistance in the damping system.<br> ~ Materal: Steel, TEC hinges feature a solid metal hinge cup. All moving mechanism parts, including pivot pins, linkages and springs are hardened to ensure long-term durability<br> ~ Soft-close damper is premounted in the hinge cup<br> ~ Adjustment switch to regulate closing action<br> ~ One piece hinge and base plate combination<br> ~ 3 dimensional adjustment<br> ~ 11 mm (7/16”) cup drilling depth<br> ~ Front locating tabs position hinge on face frame<br> ~ Cam side adjustment<br> ~ Cam depth adjustment<br> ~ Height adjustment at mounting screw<br> ~ Works with current Grass insertion machinery<br> ~ Includes 1x #10 x 3/4" Wood Screw<br> ~ Side Cam Adjustment: +/-1.5mm(1/16")<br> ~ Height Adjustment: +/-2mm(3/32")<br> ~ Depth Cam Adjustment: +3mm(1/8")<br> ~ Screw hole distance: 45mm (1-25/32")<br> ~ Cup Boring Diameter: 35mm (1-3/8")<br> ~ Hinge Overlay: 1-1/2"<br> ~ Series: TEC 864<br> ~ Cabinet Type: Face Frame<br> ~ Fixing Type: Screw On<br> ~ Closing Mechanism: Soft Closing<br> ~ Hinge Opening Angle: 108 Degree<br> ~ Base Plate: Wrap Mount<br> ~ Installation Screws: Included
Details
- GRASS TEC 864 Soft Close Cabinet Hinge MADE IN THE USA
- 3-Way Adjustable In and Out Cam Adjustment 108 Degrees Opening Angle
- Screw on wrap around mount cabinet hinge Includes 2x #6 x 5/8" Wood Screws and 1x #10 x 3/4" Wood Screw
- 1-1/2 in overlay soft closing hinge with custom 3 level soft close strength switch
2 Pack Rok Hardware Grass TEC 864 108 Degree 1-1/2" Overlay 3 Level Soft Close Screw On Compact Cabinet Hinge 04549A-15 3-Way Adjustment 45mm Screw Hole Pattern
Brand: Rok
MADE IN THE USA<br><br> ~Face Frame Hinge with integrated Soft-close<br> ~ No additional installation of the Soft-close is required.<br> A three tiered adjustment switch allows various levels of resistance in the damping system.<br> ~ Materal: Steel, TEC hinges feature a solid metal hinge cup. All moving mechanism parts, including pivot pins, linkages and springs are hardened to ensure long-term durability<br> ~ Soft-close damper is premounted in the hinge cup<br> ~ Adjustment switch to regulate closing action<br> ~ One piece hinge and base plate combination<br> ~ 3 dimensional adjustment<br> ~ 11 mm (7/16”) cup drilling depth<br> ~ Front locating tabs position hinge on face frame<br> ~ Cam side adjustment<br> ~ Cam depth adjustment<br> ~ Height adjustment at mounting screw<br> ~ Works with current Grass insertion machinery<br> ~ Includes 1x #10 x 3/4" Wood Screw<br> ~ Side Cam Adjustment: +/-1.5mm(1/16")<br> ~ Height Adjustment: +/-2mm(3/32")<br> ~ Depth Cam Adjustment: +3mm(1/8")<br> ~ Screw hole distance: 45mm (1-25/32")<br> ~ Cup Boring Diameter: 35mm (1-3/8")<br> ~ Hinge Overlay: 1-1/2"<br> ~ Series: TEC 864<br> ~ Cabinet Type: Face Frame<br> ~ Fixing Type: Screw On<br> ~ Closing Mechanism: Soft Closing<br> ~ Hinge Opening Angle: 108 Degree<br> ~ Base Plate: Wrap Mount<br> ~ Installation Screws: Included
Details
- Steel Material, TEC hinges feature a solid metal hinge cup. All moving mechanism parts, including pivot pins, linkages and springs are hardened to ensure long-term durability.
Listing
| Binding | Tools & Home Improvement |
|---|---|
| Product group | Home Improvement |
| Product type | HARDWARE_HINGE |
| Model | G04549A-15-2 |
| Part number | 04549A-15 |
| Label | Grass |
| Manufacturer | Grass |
25 Pack Rok Hardware Grass TEC 864 108 Degree 1-1/2" Overlay 3 Level Soft Close Screw On Compact Cabinet Hinge 04549A-15 3-Way Adjustment 45mm Screw Hole Pattern
Brand: Rok
MADE IN THE USA<br><br> ~Face Frame Hinge with integrated Soft-close<br> ~ No additional installation of the Soft-close is required.<br> A three tiered adjustment switch allows various levels of resistance in the damping system.<br> ~ Materal: Steel, TEC hinges feature a solid metal hinge cup. All moving mechanism parts, including pivot pins, linkages and springs are hardened to ensure long-term durability<br> ~ Soft-close damper is premounted in the hinge cup<br> ~ Adjustment switch to regulate closing action<br> ~ One piece hinge and base plate combination<br> ~ 3 dimensional adjustment<br> ~ 11 mm (7/16”) cup drilling depth<br> ~ Front locating tabs position hinge on face frame<br> ~ Cam side adjustment<br> ~ Cam depth adjustment<br> ~ Height adjustment at mounting screw<br> ~ Works with current Grass insertion machinery<br> ~ Includes 1x #10 x 3/4" Wood Screw<br> ~ Side Cam Adjustment: +/-1.5mm(1/16")<br> ~ Height Adjustment: +/-2mm(3/32")<br> ~ Depth Cam Adjustment: +3mm(1/8")<br> ~ Screw hole distance: 45mm (1-25/32")<br> ~ Cup Boring Diameter: 35mm (1-3/8")<br> ~ Hinge Overlay: 1-1/2"<br> ~ Series: TEC 864<br> ~ Cabinet Type: Face Frame<br> ~ Fixing Type: Screw On<br> ~ Closing Mechanism: Soft Closing<br> ~ Hinge Opening Angle: 108 Degree<br> ~ Base Plate: Wrap Mount<br> ~ Installation Screws: Included
Details
- GRASS TEC 864 Soft Close Cabinet Hinge MADE IN THE USA
- 3-Way Adjustable In and Out Cam Adjustment 108 Degrees Opening Angle
- Screw on wrap around mount cabinet hinge Includes 2x #6 x 5/8" Wood Screws and 1x #10 x 3/4" Wood Screw
- 1-1/2 in overlay soft closing hinge with custom 3 level soft close strength switch
Listing
| Product group | Home Improvement |
|---|---|
| Product type | HARDWARE |
| Model | G04549A-15-25 |
| Part number | 04549A-15 |
| Label | Grass |
| Manufacturer | Grass |
10 Pack Rok Hardware Grass TEC 864 108 Degree 1-1/2" Overlay 3 Level Soft Close Screw On Compact Cabinet Hinge 04549A-15 3-Way Adjustment 45mm Screw Hole Pattern
Brand: Rok
MADE IN THE USA<br><br> ~Face Frame Hinge with integrated Soft-close<br> ~ No additional installation of the Soft-close is required.<br> A three tiered adjustment switch allows various levels of resistance in the damping system.<br> ~ Materal: Steel, TEC hinges feature a solid metal hinge cup. All moving mechanism parts, including pivot pins, linkages and springs are hardened to ensure long-term durability<br> ~ Soft-close damper is premounted in the hinge cup<br> ~ Adjustment switch to regulate closing action<br> ~ One piece hinge and base plate combination<br> ~ 3 dimensional adjustment<br> ~ 11 mm (7/16”) cup drilling depth<br> ~ Front locating tabs position hinge on face frame<br> ~ Cam side adjustment<br> ~ Cam depth adjustment<br> ~ Height adjustment at mounting screw<br> ~ Works with current Grass insertion machinery<br> ~ Includes 1x #10 x 3/4" Wood Screw<br> ~ Side Cam Adjustment: +/-1.5mm(1/16")<br> ~ Height Adjustment: +/-2mm(3/32")<br> ~ Depth Cam Adjustment: +3mm(1/8")<br> ~ Screw hole distance: 45mm (1-25/32")<br> ~ Cup Boring Diameter: 35mm (1-3/8")<br> ~ Hinge Overlay: 1-1/2"<br> ~ Series: TEC 864<br> ~ Cabinet Type: Face Frame<br> ~ Fixing Type: Screw On<br> ~ Closing Mechanism: Soft Closing<br> ~ Hinge Opening Angle: 108 Degree<br> ~ Base Plate: Wrap Mount<br> ~ Installation Screws: Included
Details
- GRASS TEC 864 Soft Close Cabinet Hinge MADE IN THE USA
- 3-Way Adjustable In and Out Cam Adjustment 108 Degrees Opening Angle
- Screw on wrap around mount cabinet hinge Includes 2x #6 x 5/8" Wood Screws and 1x #10 x 3/4" Wood Screw
- 1-1/2 in overlay soft closing hinge with custom 3 level soft close strength switch
50 Pack Rok Hardware Grass TEC 864 108 Degree 1-1/2" Overlay 3 Level Soft Close Screw On Compact Cabinet Hinge 04549A-15 3-Way Adjustment 45mm Screw Hole Pattern
Brand: Rok
MADE IN THE USA<br><br> ~Face Frame Hinge with integrated Soft-close<br> ~ No additional installation of the Soft-close is required.<br> A three tiered adjustment switch allows various levels of resistance in the damping system.<br> ~ Materal: Steel, TEC hinges feature a solid metal hinge cup. All moving mechanism parts, including pivot pins, linkages and springs are hardened to ensure long-term durability<br> ~ Soft-close damper is premounted in the hinge cup<br> ~ Adjustment switch to regulate closing action<br> ~ One piece hinge and base plate combination<br> ~ 3 dimensional adjustment<br> ~ 11 mm (7/16”) cup drilling depth<br> ~ Front locating tabs position hinge on face frame<br> ~ Cam side adjustment<br> ~ Cam depth adjustment<br> ~ Height adjustment at mounting screw<br> ~ Works with current Grass insertion machinery<br> ~ Includes 1x #10 x 3/4" Wood Screw<br> ~ Side Cam Adjustment: +/-1.5mm(1/16")<br> ~ Height Adjustment: +/-2mm(3/32")<br> ~ Depth Cam Adjustment: +3mm(1/8")<br> ~ Screw hole distance: 45mm (1-25/32")<br> ~ Cup Boring Diameter: 35mm (1-3/8")<br> ~ Hinge Overlay: 1-1/2"<br> ~ Series: TEC 864<br> ~ Cabinet Type: Face Frame<br> ~ Fixing Type: Screw On<br> ~ Closing Mechanism: Soft Closing<br> ~ Hinge Opening Angle: 108 Degree<br> ~ Base Plate: Wrap Mount<br> ~ Installation Screws: Included
Details
- GRASS TEC 864 Soft Close Cabinet Hinge MADE IN THE USA
- 3-Way Adjustable In and Out Cam Adjustment 108 Degrees Opening Angle
- Screw on wrap around mount cabinet hinge Includes 2x #6 x 5/8" Wood Screws and 1x #10 x 3/4" Wood Screw
- 1-1/2 in overlay soft closing hinge with custom 3 level soft close strength switch
