WORM SPEED REDUCER

Speed Reducer: 117 Nominal Output RPM, 56C, 15:1, 1.5 hp Max. Input HP This listing is for each. Bearing Type Tapered Roller Finish Painted Housing Material Cast Iron Maximum Input HP 1.72 Mount Type Threaded NEMA/IEC Frame 56C Nominal Ratio 15:1 Number of Stages 1 Output Torque 840 in-lb Overhung Load 700 lb Performance Continuous Seal Type Double-Lipped Series Worm Gear Shaft Orientation Right Angle Speed Input 1750 rpm Speed Output 116.7 rpm Style Single Output Type Speed Reducer Worm Center Distance 2-1/16 Product Weight 27 Notes Long recognized as a pioneer among OEM and MRO manufacturers, Boston Gear has been producing dependable products since 1877 - and at the top of the list is our 700 Series worm gear speed reducer. Our 700 Series is known throughout the industry for its durable, efficient, and trouble-free performance. Fine grain, cast iron one piece housing Integral input worm and shaft made of high strength, case hardened steel for long life Right angle speed reducers will fit all standard NEMA C-face motors Quill mount design Mounting holes on top and bottom Units shipped less oil Single output shaft Quill mount to c-face motor. Using right-angle worm gearing, speed is reduced and torque is multiplied. Output shaft transmits torque to user application.
