Functional Devices . PSH100A100AB10

RIB Power Supply PSH100A100AB10, Enclosed, Dual, 100VA, 120-24VAC, 10A Breaker The enclosed models feature one or two transformers pre-packaged in a NEMA 1 enclosure and are intended for mounting in the enclosure of the user's choice. The transformers are available in 40VA, 75VA, and 100VA. A switch / circuit breaker is provided for each transformer and on B10 models a switch / circuit breaker is present for controlling power for the entire unit. An LED indicates the presence of 24 Vac on the Class 2 terminals on the outside of the enclosure, or wires on the inside. An internal high-voltage wiring compartment and two 120 Vac grounded convenience outlets are provided on most models. Each power supply series is available with a number of various options. Height : 4.5 in Phase - Electrical : 1 Mounting - Transformer : Wall Temp. Rise : Not Rated Enclosure Finish : Powder Coated Input Voltage - Transformer : 120V AC Standards : CE, cUL, Special Seismic Certification of Equipment and Components: OSP-0201-10, UL 5085-3, UL 916 Protective Device : Circuit Breaker Hz - Electrical : 50 Hz, 60 Hz Width : 8.62 in Mounting : Multi Enclosure Type : Enclosed Item : Class 2 Transformer Phase : 1 Output Voltage : 24VAC VA Rating - Transformer : (2) 100VA Output Voltage - Transformer : 24V AC Primary Connection : Pigtails Depth : 4.5 in Enclosure Rating : NEMA 1 Item - Transformer : Class 2 Transformer VA Rating : (2) 100 Green Environmental Attribute : Product Contributes To Reducing Energy Consumption Enclosure Style - Transformer : Enclosed Input Voltage : 120VAC Includes : finger-safe terminals, 10AmpMain Breaker Switch, LED Power Indicator, 120Vac convenience outlets, Made In USA, On/Off Control Secondary Connection : Screw Terminals Hz : 50/60 Country of Origin (subject to change) : United States

Dual 100 VA, 120 Vac to 24 Vac, UL Class 2, 10 Amp Main Breaker, Metal Enclosure

<p><b>Description</b><ul><li>Transformer: Two 100 VA Split-Bobbin Over Current Protection: Circuit Breaker Frequency: 50/60 Hz 24 Vac ON/OFF: On / Off Switch & Breaker Main Breaker ON/OFF: Switch / Breaker (10 Amp) (Kills power to entire unit: Outlets, Aux. Output, & Transformer) Total Combined Output 9A Approvals: Class 2 (UL Approved UL5085-3), UL916, UL508, C-UL, CE, RoHS, Special</li><li> Product Type: Power Supply </li><li> Input: 120 Vac </li><li> VA Rating: 100 </li><li> Frequency: 50-60 Hz </li><li> Power Supply: Class 2 </li><li> Type: Dual</li></ul></p>
