Kunkle Pressure Relief Valve - 1-1/2" 0537-G01-HM0130 Cast Iron, 130 PSI Steam ASME Section IV Hot Water
Brand: Kunkle Pressure Relief Valve
Kunkle Model 537 Safety Relief Valve (SRV) is designed for liquid or steam relief through a threaded side outlet port. These valves are used for ASME Section IV, HV low pressure hot water boilers for liquid/steam service. Working well in steam generator, hot water boiler or heat exchanger applications. The Series 537 valve is set to the pressure listed in the item title. Each valve is tested and inspected for pressure setting and leakage This is a long service life valve due to the extra heavy body Top Guided disc assembly includes a resilient seal in the seating area Includes a heavy duty lift lever The pivot between the sping and disc aides in the correction for misalingment. Spring side thrust compensation with pivot
Details
- The Kunkle Model 537, Pressure Relief Valve, is excellent for relieving overpressure created by thermal expansion under normal firing conditions in low pressure hot water boilers. Also works well in applications where overpressure in the form of water or steam has been created in over-firing by a failure in the control system. The valve has a set pressure for relief at 130 PSI.
- Brand Name|Kunkle MFR Part Number|0537-G01-HM0130 Item|Liquid or Steam Relief Valve Service|Steam ASME Section IV Hot Water Inlet Connection FNPT|1-1/2" Outlet Connection FNPT|2" Body Material|Cast Iron A126 Class A/B Set Pressure PSI|130 Working Temperature|-20 Deg F to 250 Deg F Standard/Approvals|Steam ASME Section IV Hot Water
Listing
| Product group | BISS |
|---|---|
| Product type | VALVE |
| Part number | 0537-G01-HM0130 |
| Items per pack | 1 |
| Label | Kunkle Pressure Relief Valve |
| Manufacturer | Kunkle Pressure Relief Valve |
Catalog
| Feature | The Kunkle Model 537, Pressure Relief Valve, is excellent for relieving overpressure created by thermal expansion under normal firing conditions in low pressure hot water boilers. Also works well in applications where overpressure in the form of water or steam has been created in over-firing by a failure in the control system. The valve has a set pressure for relief at 130 PSI. |
|---|---|
| Category | Industrial & Scientific |
| MPN | 0537-G01-HM0130 |
| Product group | BISS |
| Product type | MECHANICAL_COMPONENTS |
| Manufacturer | Kunkle Pressure Relief Valve |
