[Item]Specifications <br> [Transmission method]One-way time-sharing multiplex transmissions <br> [Transmission points]32 inputs(2 ports),32 outputs(2 ports) <br> [External power supply voltage *1]12 to 24 V DC(allowable voltage range: 10.8 to 26.4 V) <br> [External supply current *2] 80 mA min. <br> [Minimum input time *3] <br> High-speed 16 ms <br> Standard 2.4 ms <br> [I/O memory Allocations]Each Unit is allocated 4 words in the I/O Area (which starts at CIO 0000). <br> The words are allocated according to the mounting position of the Unit. <br> [Transmission error bit]A transmission error bit for each input port is allocated in the Basic I/O Unit Information Area. <br> [Cables] <br> VCTF,0.75 mm^2,3 conductors(power supply on one side(common power supply)) <br> VCTF,0.75 mm^2,2 conductors(power supply on both sides(separate power supplies)) <br> Shielded cable,0.75 mm^2,3 conductors(power supply on one side(common power supply)) <br> Shielded cable,0.75 mm^2,2 conductors(power supply on both sides(separate power supplies)) <br> Note1. When separate power supplies are used,the B7A Interface Unit and B7A Link Terminal are supplied by separate external power supplies. <br> 2. When a common power supply is used,the B7A Interface Unit and B7A Link Terminal are supplied by the sameexternal power supply. <br> *1. We recommend OMRON S8[][]-series Power Supply Units for the external power supplies. <br> *2. The capacity of the external supply current does not include the capacity required by the B7A Link Terminal. <br> *3. The minimum input time is the minimum time required by the B7A Interface Unit to read the input signals from the CPU Unit.<br><br><br>(1)
