Mean Well Power Supply, Ac-Dc, 48V, 1.6A - LRS-75-48

This item will ship LRS-75-48*1pcs,enjoy shopping and best wishes!

<b>Features</b><br>No load power consumption <0.2W for 35W/50W;<0.3W for 75W/100W<br>Universal AC input / Full range<br>Withstand 300VAC surge input for 5 seconds<br>Ultra compact and 1U low profile<br>Withstand 5G vibration test<br>High operating temperature up to 70oC<br>Protections: Short circuit / Overload / Over voltage<br>Cooling by free air convection<br>Compliance to IEC/EN60335-1(PD3) and IEC/EN61558-1,-2-16 for household appliances<br>Operating altitude up to 5000 meters<br>High efficiency, long life and high reliability<br>LED indicator for power on<br>Low cost<br>3 years warranty

<p><b>Features:</b></p> <p>No load power consumption <0.2W for 35W/50W; <0.3W for 75W/100W</p> <p>Universal AC input / Full range</p> <p>Withstand 300VAC surge input for 5 seconds</p> <p>Ultra compact and 1U low profile</p> <p>Withstand 5G vibration test</p> <p>High operating temperature up to 70oC</p> <p>Protections: Short circuit / Overload / Over voltage</p> <p>Cooling by free air convection</p> <p>Compliance to IEC/EN60335-1(PD3) and IEC/EN61558-1,-2-16 for household appliances</p> <p>Operating altitude up to 5000 meters</p> <p>High efficiency, long life and high reliability</p> <p>LED indicator for power on</p> <p>Low cost</p> <p>3 years warranty</p> <p><b>General Specification (Please refer to images below for detailed datasheet)</b></p> <p>AC input voltage range:85~264VAC; 120~370VDC</p> <p>AC inrush current (max.):Cold start, 45A at 230VAC</p> <p>DC adjustment range:±10% by potentiometer</p> <p>Overload protection Range:110%~150%</p> <p>Overload protection Type:Hiccup mode, auto-recovery</p> <p>Over voltage protection Range:115%~135% rated output voltage</p> <p>Over voltage protection Type:Shut down o/p voltage, re-power on to recover</p> <p>Withstand voltage:3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 1.25kVAC, 1 minute</p> <p>Working temperature:-30~+70°C (refer to output derating curve)</p> <p>Safety standards:UL60950-1, IEC/EN60950-1, IEC/EN61558-1, EN61558-2-16, IEC/EN60335-1, CCC GB4943 approved</p> <p>EMC standards:EN55022 class B, EN55014, EN61000-3-2, 3, EN61000-4,2,3,4,5,6,8,11, GB9254</p> <p>Connection:5P/9.5mm pitch terminal block</p> <p>Dimension (LxWxH):99x 97x 30</p>

Welcome,you can buy all of the MEAN WELL power supplies in <strong>Power home</strong>.<br /> <br /> We are MEAN WELL agents,there are more than 5000 kinds of products in stock,ensure rapid delivery,price advantage,if you are business customer or purchase <strong>more than 20 pcs</strong>,please contact us for a more favorable price!<br /> <br /> Note:too cheap products may be imitation or defective products,usually a few months later may be broken,the original product can be used for 5 years or more,the power will not burn the equipment,this is the real bargain!

Model: LRS-75-48 </br> Input: 85 to 264V AC </br> Output: 48V 1.6A </br> Size: 99x97x30mm (L * W * H) </br> 100% load burn-in test </br> Small, high power den </br>
