CRL LSWM28MBL Matte Black Double Roller Laguna Series Wall Mount Bi-Parting Slider with Softbrake Kit

CR Laurence . LSWM28MBL

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerCR Laurence
Attribute00, Attribute07Matte Black
Attribute01Stainless Steel (Alloy 316)
Attribute0298-7/16
Attribute03Double Door
Attribute04104
Attribute053/8, 1/2
Attribute06Tempered Insulated
Attribute08Yes
Attribute0937-13/16
Attribute10, Weight100
Attribute111-1/4
Attribute12Flush, Surface
AttributeKey00Finish
AttributeKey01Material
AttributeKey02Maximum Door Height
AttributeKey03Door Configuration
AttributeKey04Track Length
AttributeKey05Glazing Thickness
AttributeKey06Glazing Type
AttributeKey07Finish/Color
AttributeKey08Anti-Lift
AttributeKey09Minimum Door Width (Inches)
AttributeKey10, Weight_AttribMaximum Panel Weight (Pounds)
AttributeKey11Track Diameter (Inches)
AttributeKey12Door Attachment
CategoryIdL3Laguna Series Sliding Glass Door Systems
CategoryL1Architectural Hardware
CategoryL2Sliding Glass Doors
Extra Product NameCRL LSWM28MBL Matte Black Double Roller Laguna Series Wall Mount Bi-Parting Slider with Softbrake Kit
WeightUnitlbs
atoms, moq, multiple, tierMinQty11
extendedQty, qtyInStock0
MPNLSWM28MBL
qtySourceupdateFromUrlEntry
snippet<br/> The <b>CRL Double Roller Laguna Series Wall Mount Bi-Parting Slider with Softbrake Kit</b> contains all the components you will need (except the tempered glass) to complete the installation. The Softbrake braking system helps to control the last 2-1/4" (57 mm) of travel. This model is used in applications where you are attaching two bi-parting sliding doors to the inside face of a sufficiently reinforced wall.<br/> The Anti-Lift Sliding Door Top Rollers can be attached to the glass with either Surface Mount or Flush Mount Fittings (both are supplied). The Rollers have a 1/8" (3 mm) up or down vertical adjustment to aid in door alignment. This system should only be used with 3/8" or 1/2" (10 or 12 mm) tempered glass. Laminated glass cannot be used.<br/><b>DOOR SYSTEM LIMITATIONS:</b><br/> Maximum Door Weight: 220 Lbs. (100 kg)<br/> Minimum Door Width: 37-13/16" (960 mm)<br/> Maximum Door Width: 53-9/16" (1.36 m)<br/> Maximum Door Height: 98-7/16" (2.50 m)<br/> Maximum Track Length: 104" (2.64 m)<br/><b>Product Warning:</b><br/><b>STRUCTURAL DISCLAIMER</b> - All customers who in any way utilize this product are solely responsible to consult a structural engineer to determine the suitability of the product for the intended use and site conditions. All installers must be qualified and have professional knowledge about compliance with local, state and federal regulations, safety factors, and the appropriate choice of fixing material and procedures.<br/><p>.</p>
tierPrice12328.82

Distributor offers

SellerSKUMOQIn stockMultiplePrices
DK HardwareLSWM28MBL111 @ $2328.82
