MASTER CYLINDER WIL-261-14963-P from WILWOOD

<ul><b>Includes:</b><li><b>Polished</b> Tandem Chamber Master Cylinder</li><ul><li>1" Bore cylinder <b>without</b> the push rod</li></ul><li>Combination Proportioning Valve</li><li>Stainless Steel Fluid Tubes</li><ul><li>Precision bent w/ pre-installed stainless tube nuts for a simple bolt-on install</li></ul><li>Mounting Bracket</li><ul><li>Black e-coating will give years of durable, rust-free performance</li></ul><li>Stainless Steel Button Head Bolts</li></ul></ul><br><ul><b>Wilwood Compact Tandem Chamber Master Cylinder Details:</b><li>Packaged is the new Compact Tandem Chamber Master Cylinder with Combination Proportioning Valve, L/H mounting bracket, fluid tubes & mounting hardware in a kit. It represents the latest in refinements in brake pressure actuation & fluid control in a compact package with only 6.55" from mounting flange to end.</li> <li>The slotted flange mounting makes it a simple bolt on for many OE mounts including Chrysler, Corvette, GM & Ford Mustang bolt patterns & is compatible w/ manual or power brake system applications. Master cylinders w/out pushrods are generally intended for power brake use & available in two bores sizes, 1.00" or 1-1/8"</li> </ul> <br> <ul><b>Wilwood Combination Proportioning Valve Details:</b> <li>Simplifies mounting, fluid circuit plumbing, brake light wiring & brake bias adjustments on modified, custom built, or competition vehicles equipped w/ brake system upgrades.</li> <li>Maintains full separation between the front & rear fluid circuits when used w/ tandem outlet or dual mount master cylinder assemblies.</li> <li>Bias proportioning adjustment is provided in the rear fluid circuit.</li> <li>The front circuit has a single inlet 7 two outlets for optional line routing</li> <li>A fluid port with a pressure switch responds instantly to pressure in the front fluid circuit for brake light activation. wiring pigtail w/ protective boot is included w/ switch.</li> </ul>

Wilwood 261-14963-P Compact Tandem Master Cylinder With Proportioning Valve & Left-Hand Bracket, 1-inch Bore, Media Burnished Finish *** Accesspeed has packaged Wilwood's new Compact Tandem Chamber Master Cylinder with the Combination Proportioning Valve, L/H mounting bracket, fluid tubes and mounting hardware in a kit. Tandem Master Cylinder represents the latest in refinements in brake pressure actuation and fluid control in a compact package with only 6.55" from mounting flange to end. The slotted flange mounting makes it a simple bolt on for many OE mounts including the popular Chrysler, Corvette, GM, and Ford Mustang bolt patterns and is compatible with manual or power brake system applications. Master cylinders without pushrods are generally intended for power brake use and available in two bores sizes, 1.00" or 1-1/8", and two finishes, ball burnished or black E-coat. The combination proportioning valve substantially simplifies wiring and brake proportioning adjustments on vehicles with custom brake systems. The combination block maintains full isolation between front and rear fluid circuits and is specifically designed to accompany the Tandem Chamber Master Cylinder. The combo valve and left-hand side bracket are black E-coated for a performance look and long lasting durability. Stainless steel fluid tubes are precision bent with preinstalled plated steel tube nuts for a simple bolt-on installation between the Combination Proportioning Valve and the Wilwood Tandem Master Cylinder. Stainless steel button head fasteners thread into the bracket for a simple installation and years of durable, rust-free performance. Simply connect the fluid lines, bleed the system, and you're finished.
