Mersen - ATDR17-1/2 Fuse - Time-Delay - Class CC - 600VAC - 17-1/2A

'Use a fuse from Mersen/Ferraz Shawmut to increase efficiency with your electrical system. With time delay fuse speed, 17-1/2A fuse amps, an interrupt rating of 200kA at 600VAC, 100kA at 300VDC, and atdr series, this fuse is a must-have. Functionally equal to Bussmann LP-CC, Littelfuse CCMR, you'll thoroughly enjoy its use. The body is made of melamine material. As far as size goes, it is 13/32" in diameter. It is a nonindicating fuse. The voltage rating is 600vac/300vdc. When it comes to product classification, this item can be grouped as CC. It has a dual element. Standards include: UL/CSA.'

<p><ul><li>Time delay for motor starting inrush currents without nuisance opening</li><li>Highly current-limiting for low peak let-thru current</li><li>Improved cycling ability for frequent motor starts/stops without nuisance fuse opening</li><li>Rejection-style design prevents replacement errors (when used with recommended fuse blocks)</li><li>Metal-embossed date and catalog number for traceability and lasting identification</li><li>Fiberglass body provides dimensional stability in harsh industrial settings</li><li>High-grade silica filler ensures fast arc quenching and optimum current limitation</li></ul></p> ,<p><b>Specifications: </b><ul><li>Fuse Type:-Time Delay / Current Limiting </li><li> Fuse Class:-CC </li><li> Mounting Type:-Ferrule </li><li> Ampere Rating:-17.5 A </li><li> Volt Rating:-600V AC, 300V DC </li><li> Overall Length:-1-1/2 in </li><li> Diameter:-.4063 in </li><li> Series:-ATDR </li><li> UL Approvals:-Standard 248-4 </li><li> CSA Approval:-Standard C22.2 No.248.4 </li><li> DC Listed UL Approval:-Standard 198L </li><li> Body Type:-Fiberglass </li></ul></p>
