CRL ALUM-LSWM7MBL-VCP-1 Matte Black Laguna Series Wall Mount Single Slider with Softbrake Kit

CRL-USALUM . ALUM-LSWM7MBL-VCP-1

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerCRL-USALUM
Attribute00, Attribute07Matte Black
Attribute01Stainless Steel (Alloy 316)
Attribute0298-7/16
Attribute03Single Door
Attribute04104
Attribute053/8, 1/2
Attribute06Tempered Insulated
Attribute08Yes
Attribute0937-13/16
Attribute10, Weight100
Attribute111-1/4
Attribute12Flush, Surface
AttributeKey00Finish
AttributeKey01Material
AttributeKey02Maximum Door Height
AttributeKey03Door Configuration
AttributeKey04Track Length
AttributeKey05Glazing Thickness
AttributeKey06Glazing Type
AttributeKey07Finish/Color
AttributeKey08Anti-Lift
AttributeKey09Minimum Door Width (Inches)
AttributeKey10, Weight_AttribMaximum Panel Weight (Pounds)
AttributeKey11Track Diameter (Inches)
AttributeKey12Door Attachment
CategoryIdL3Laguna Series Sliding Glass Door Systems
CategoryL1Architectural Hardware
CategoryL2Sliding Glass Doors
Extra Product NameCRL ALUM-LSWM7MBL-VCP-1 Matte Black Laguna Series Wall Mount Single Slider with Softbrake Kit
WeightUnitlbs
atoms, moq, multiple, tierMinQty11
extendedQty, qtyInStock0
MPNALUM-LSWM7MBL-VCP-1
qtySourceupdateFromUrlEntry
snippet<br/> The <b>CRL Laguna Series Wall Mount Single Slider with Softbrake Kit</b> contains all the components you will need (except the tempered glass) to complete a single door installation. The Softbrake braking system helps to control the last 2-1/4" (57 mm) of travel. This model is used in applications where you are attaching a single sliding door to the inside face of a sufficiently reinforced wall.<br/> The Anti-Lift Sliding Door Top Rollers can be attached to the glass with either Surface Mount or Flush Mount Fittings (both are supplied). The Rollers have a 1/8" (3 mm) up or down vertical adjustment to aid in door alignment. This system should only be used with 3/8" or 1/2" (10 or 12 mm) tempered glass. Laminated glass cannot be used.<br/><b>DOOR SYSTEM LIMITATIONS:</b><br/> Maximum Door Weight: 220 Lbs. (100 kg)<br/> Minimum Door Width: 37-13/16" (960 mm)<br/> Maximum Door Width: 53-9/16" (1.36 m)<br/> Maximum Door Height: 98-7/16" (2.50 m)<br/> Maximum Track Length: 104" (2.64 m)<br/><p>.</p>
tierPrice11196.93

Distributor offers

SellerSKUMOQIn stockMultiplePrices
DK HardwareALUM-LSWM7MBL-VCP-1111 @ $1196.93
