Hubbell Wiring Devices 3P4W 60A 250V Valox Pin&sleeve Connectorecto Rohs Compliant: Yes - HBL460C9V05

Technical Specification Item - Plugs and Receptacles Watertight Pin and Sleeve Connector Body Material - Pin and Sleeve Zytel 801 Nylon Amps - Plugs and Receptacles 60 Voltage - Plugs and Receptacles 250V AC Color - Plugs and Receptacles Blue Number of Poles 3 Number of Wires 4 Phase - Electrical 3 Switch Rated No Grounding Style IEC HP 5 Features Abuse Resistant Standards C22.2 No. 182.1, CSA Certified File No: LR280C, IEC 60309-1 and 60309-2, UL Listed File No: E146033, UL1682 and UL1686C2 Item Pin and Sleeve Connector This listing is for each. Product Specification Amperage Rating 60 Application High Ampacity Connections, Pin Mod Brand Hubbell Wiring Device-Kellems Catalog Description Hubbell Wiring Device Kellems, Heavy Duty Products, IEC Pin and SleeveDevices, Industrial Grade, Female, Connector Body, 60A 3-Phase Delta250V AC, 3-Pole 4-Wire Grounding, Terminal Screws, Black, V-0Flammability Version Conductor Range #6AWG to #4AWG Connection Pressure Screw Terminal Current Rating 60 Environmental Conditions Watertight Finish 2 Black 00783585404820 Height 5.0000 Height Unit IN Insulation Insulated Body Item Status A Length 11.7500 Length UOM IN Material Composite Mfr. # HBL460C9V05 Mounting Cord Mounted NEMA Rating Non-NEMA Number Of Conductors 5-Wire Grounding Number Of Poles 4 Ships Freight No Ships Ground. Eligible for expedited shipping Yes Size Standard Special Features Watertight Standard UL 498, IEC 309-1 and 309-2 Sub-Brand Pin and Sleeve Temperature Rating Maximum Continuous: 75 C; Minimum Continuous: -40 C w/o impact, -25 with impact. Type Standard Voltage Rating 3-Phase 600V AC kV Width 5.7500 Width UOM IN
