Mean Well Power Supply, Ac-Dc, 3.3V, 7A Rohs Compliant: Yes - RS-35-3.3

<p><b>Features:</b></p> <p>No load power consumption <0.5W</p> <p>All using 105°C long life electrolytic capacitors</p> <p>Protections: Short circuit / Overload / Over voltage</p> <p>Meet EMS EN50082-2/EN61000-6-2</p> <p>heavy industry level (35~150W)</p> <p>Withstand 300VAC surge input for 5 sec.</p> <p>High operating temperature up to 70°C</p> <p>Withstand 5G vibration test</p> <p>Miniature size, high power density</p> <p>High efficiency, long life and high reliability</p> <p>LED indicator for power on</p> <p>100% full load burn-in test</p> <p>Suitable for critical applications</p> <p>3 years warranty</p> <p><b>General Specification (Please refer to images below for detailed datasheet)</b></p> <p>AC input voltage range:88~264VAC, 125~373VDC</p> <p>AC inrush current (max.):36A at 230VAC</p> <p>DC adjustment range:±10% by potentiometer for single output; CH1 -5%~+10% by potentiometer for multiple output</p> <p>Overload protection:110%~150% hiccup mode, auto-recovery</p> <p>Over voltage protection:115%~135% rated output voltage, hiccup mode, auto-recovery</p> <p>Withstand voltage:I/P - O/P: 3kVAC, I/P - FG: 1.5kVAC, O/P - FG: 0.5kVAC, 1 minute</p> <p>Working temperature:-20~+70°C</p> <p>Vibration:10~500Hz, 5G 10min. /1 cycle, period for 60 min. each along X, Y, Z axes</p> <p>Safety standards:UL60950-1, TUV EN60950-1 approved</p> <p>EMC standards:EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2) (35~150W)</p> <p>Connection:Terminal block for input and output</p> <p>Dimension (LxWxH):99x 82x 36</p> <p>Case No.:932A</p> <p>Packing:45pcs /14.0kg</p>

<b>Features</b><br>No load power consumption <0.5W (RS-15~75)<br>All using 105¡æ long life electrolytic capacitors<br>Protections: Short circuit / Overload / Over voltage / Over Temp.(RS-15)<br>Meet EMS EN50082-2/EN61000-6-2 heavy industry level (35~150W)<br>Withstand 300VAC surge input for 5 sec.<br>High operating temperature up to 70¡ãC<br>Withstand 5G vibration test<br>Miniature size<br>Long life and high reliability<br>LED indicator for power on<br>100% full load burn-in test<br>Suitable for critical applications<br>3 years warranty<br>The transaction does not include any Import Tax / Duty / VAT / Brokerage Fees / Handling Fees. For more information about the tax rate, please check with local custom department before purchases. If you reject the package due to any charged tax or duty, we reserve the right to charge ALL shipping cost and 5% (of total price) handling fee. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. We do not responsible for any custom duty or import tax. Please check with your country's customs office to determine what these additional costs will be prior to buying. Sometime customs will inspect the parcel and sometime will not. If you have any special request, please kindly advise us once place order.

Welcome,you can buy all of the MEAN WELL power supplies in <strong>Power home</strong>.<br /> <br /> We are MEAN WELL agents,there are more than 5000 kinds of products in stock,ensure rapid delivery,price advantage,if you are business customer or purchase <strong>more than 20 pcs</strong>,please contact us for a more favorable price!<br /> <br /> Note:too cheap products may be imitation or defective products,usually a few months later may be broken,the original product can be used for 5 years or more,the power will not burn the equipment,this is the real bargain!

<b>Features</b><br>No load power consumption <0.5W (RS-15~75)<br>All using 105¡æ long life electrolytic capacitors<br>Protections: Short circuit / Overload / Over voltage / Over Temp.(RS-15)<br>Meet EMS EN50082-2/EN61000-6-2 heavy industry level (35~150W)<br>Withstand 300VAC surge input for 5 sec.<br>High operating temperature up to 70¡ãC<br>Withstand 5G vibration test<br>Miniature size<br>Long life and high reliability<br>LED indicator for power on<br>100% full load burn-in test<br>Suitable for critical applications<br>3 years warranty<br>The transaction does not include any Import Tax / Duty / VAT / Brokerage Fees / Handling Fees. For more information about the tax rate, please check with local custom department before purchases. If you reject the package due to any charged tax or duty, we reserve the right to charge ALL shipping cost and 5% (of total price) handling fee. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. We do not responsible for any custom duty or import tax. Please check with your country's customs office to determine what these additional costs will be prior to buying. Sometime customs will inspect the parcel and sometime will not. If you have any special request, please kindly advise us once place order.

Mingweft power suppliers worldwide (DC output) ranked the third and the top 2 power plants mostly use ODM/OEM as the main source of revenue, while 99% of the proceeds come from standard power supply, is a power supply manufacturer with its own brand - MEAN WELL as the main operating strategy. The product is highly efficient and high quality and is generally covered by 3 years warranty
