FDPF12N50NZ FDPF12N50 500V 11.5A 520mΩ N-Channel UniFET II MOSFET Package: TO-220F Qty: 2pcs
Brand: Fairchild
UniFETTM II MOSFET is Fairchild Semiconductor’s high voltage MOSFET family based on advanced planar stripe and DMOS technology. This advanced MOSFET family has the smallest on-state resistance among the planar MOSFET, and also provides superior switching performance and higher avalanche energy strength. In addition, internal gate-source ESD diode allows UniFET II MOSFET to withstand over 2kV HBM surge stress. This device family is suitable for switching power converter applications such as power factor correction (PFC), flat panel display (FPD) TV power, ATX and electronic lamp ballasts.
Details
  • RDS(on) = 460 mΩ (Typ.) @ VGS = 10 V, ID = 5.75 A
  • Low Gate Charge (Typ. 23 nC )
  • Low Crss (Typ. 14 pF )
  • 100% avalanche tested
  • ESD Improved Capability / RoHS Compliant
