Kyocera

<ul><li>Replaceable Drill Tip</li><li>General Purpose</li><li>Low Cutting Force Design Improves Hole Accuracy</li><li>Optimal Web Thickness Limits Deflection</li></ul><p>Product Details:</p><ul><li>Insert Style: DA</li><li>Insert Size: 1730</li><li>Chipbreaker: M-GM</li><li>Insert Grade: PR1535</li><li>Material: Carbide</li><li>Coating Process: PVD</li><li>Coating / Composition: MEGACOAT NANO</li><li>[DC] Tip Cutting Diameter (Decimal Inch): 0.6811</li><li>[DC] Tip Cutting Diameter (mm): 17.30 </li><li>[k8] Dimension Tolerance (Decimal Inch): +0.0011, 0</li><li>[k8] Dimension Tolerance (mm): +0.027, 0</li><li>[PL] Point Length (Decimal Inch): 0.1150</li><li>[PL] Point Length (mm): 2.92</li><li>Insert Seat Size: 170</li><li>Insert Tip Angle (Degree): 140</li><li>Primary Workpiece Material: (P) Steel, (M) Stainless Steel</li><li>Insert Hand: Right-Hand</li><li>Insert Holding Method: Screw</li><li>Number of Cutting Edges: 2</li><li>Series: DRA Magic Drill</li><li>Application: Drilling</li><li>Compatible Holders (Partial): SS0750-DRA170M..., SF0750-DRA170M..., SS18-DRA170M..., SF20-DRA170M...</li></ul>DRA Magic Drill BrochureAutomotive Tooling Solutions Brochure
