Dorian MTGNR10-3B | Turning Toolholder Tnmg Mountingnr10-3b Rh | 41T757 | Raptor Supplies Worldwide

Technical Specification Item Indexable Turning Toolholder Toolholder Style MTGN Insert Style TNM. Insert Shape Triangle Approach Angle 90 Degrees Overall Length 4-1/2 Shank Width 5/8 Cutting Direction Right Hand Rake Negative ANSI Code MTGNR103B Cutting Application Turning Cutting Height 5/8 Features Hardened to 44 HRC Head Length 1 Insert Clearance Angle 0 Degrees Insert Holding Type Clamp and Lock Pin Insert Inscribed Circle 3/8 Insert Size 322 ISO Number MTGNR103B Shank Height 5/8 Shank Material Alloy Steel Side Cutting Edge Angle 0 Degrees This listing is for each. Insert Shape : Triangle Type : TNMG Holder Clamp : CL-6 Insert Screw : NL-34L Shank : Square Shim : ITSN-322 Item : Indexable Turning Toolholder Rake : Negative Style : MTGNR10-3B Clamp Screw : XNS-36 Cutting Direction : Right Hand Insert Size : 322 Overall Length : 4-1/2 in Approach Angle : 90 Degrees Shank Material : Alloy Steel Features : Hardened to 44 HRC Insert Holding Type : Clamp and Lock Pin Head Length : 1 in Cutting Height : 5/8 in Cutting Application : Turning Shank Width : 5/8 in ANSI Code : MTGNR103B Shank Height : 5/8 in Side Cutting Edge Angle : 0 Degrees ISO Number : MTGNR103B Insert Clearance Angle : 0 Degrees Insert Inscribed Circle : 3/8 in Insert Style : TNM. Toolholder Style : MTGN Country of Origin (subject to change) : United States
