Photoelectric sensors XU, XUY, fork, pot +/-, 5X95mm, 12...24 VDC, M8 | Mayer Electric

SQUARE D . SQDXUYFNEP100005

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerSQUARE D
Attribute005 mm
Attribute01Application
Attribute021 male connector M8, 4 pins
Attribute03PNP and NPN
Attribute041 NO or 1 NC programmable
Attribute05Telemecanique Photoelectric sensors XU
Attribute0695 mm
Attribute07detection on small conveyor || detection of double sheet || detection of reference marks || detection on vibrating rail || detection of labels
Attribute08infrared LED, modulated
Attribute09thru beam
Attribute10fork
Attribute11DC
Attribute12photo-electric sensor
Attribute13XUY
Attribute145-5 mm
Attribute15metal/plastic
Attribute164-wire
Attribute1718 months
Attribute1840 mA no-load
Attribute190.2 mm
Attribute2010 kHz
Attribute21discrete
Attribute22green
Attribute23adjustment mode and keypad locking 1 LED red) || output state 1 LED yellow)
Attribute24sensitivity by numeric potentiometer
Attribute25330 nF
Attribute2610-30 V DC
Attribute27-20-20 ?s
Attribute28100 mA overload and short-circuit protection)
Attribute29painted aluminium and polyamide/glass
Attribute30solid state
Attribute310.19 kg
Attribute3212...24 V DC reverse polarity protection
Attribute33, Attribute34Yes
Attribute35Pro-active compliance (Product out of EU RoHS legal scope)
Attribute36Reference contains Substances of Very High Concern above the threshold
Attribute37Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Attribute38CE || cULus
Attribute39-20-60 ?C
Attribute40-30-80 ?C
Attribute41IP65 IEC 60529
Attribute4210000 lux natural light || 5000 lux incandescent bulb
Attribute437 gn +/- 0.75 mm 10-55 Hz) IEC 60068-2-6
Attribute4430 gn 11 ms) IEC 60068-2-27
AttributeKey00, width_AttribPassage Width
AttributeKey01Series Name
AttributeKey02Electrical Connection
AttributeKey03Discrete Output Type
AttributeKey04Discrete Output Function
AttributeKey05Range Of Product
AttributeKey06, length_AttribPassage Depth
AttributeKey07Product Specific Application
AttributeKey08Emission
AttributeKey09Detection System
AttributeKey10Sensor Design
AttributeKey11Supply Circuit Type
AttributeKey12Electronic Sensor Type
AttributeKey13Sensor Name
AttributeKey14[Sn] Nominal Sensing Distance
AttributeKey15Material
AttributeKey16Wiring Technique
AttributeKey17Warranty
AttributeKey18Current Consumption
AttributeKey19, height_AttribMinimum Object Diameter For Detection
AttributeKey20Switching Frequency
AttributeKey21Type Of Output Signal
AttributeKey22Keypad Type
AttributeKey23Status Led
AttributeKey24Setting-Up
AttributeKey25Load Capacitance
AttributeKey26Supply Voltage Limits
AttributeKey27Time Response
AttributeKey28Switching Capacity In Ma
AttributeKey29Enclosure Material
AttributeKey30Output Type
AttributeKey31, Weight_AttribNet Weight
AttributeKey32[Us] Rated Supply Voltage
AttributeKey33Rohs Exemption Information
AttributeKey34Mercury Free
AttributeKey35Eu Rohs Directive
AttributeKey36Reach Regulation
AttributeKey37California Proposition 65 : WARNING: This product can expose you to chemicals including
AttributeKey38Product Certifications
AttributeKey39Ambient Air Temperature For Operation
AttributeKey40Ambient Air Temperature For Storage
AttributeKey41Ip Degree Of Protection
AttributeKey42Immunity To Ambient Light
AttributeKey43Vibration Resistance
AttributeKey44Shock Resistance
DimensionUnitmm
Extra Product NamePhotoelectric sensors XU, XUY, fork, pot +/-, 5X95mm, 12...24 VDC, M8 | Mayer Electric
UPC3389119006347
Weight0.19
WeightUnitkg
diameter, height0.2
jsonUrlData/Product/SQUARE-D-Photoelectric-sensors-XU-XUY-fork-pot-5X95mm-12-24-VDC-M8-3389119006347
jsonUrlData28eee9bfd-795b-4061-880b-aeea0058b94a
length95.0
moq, multiple, tierMinQty11
MPN, SKUSQDXUYFNEP100005
qtyInStock0
tierPrice1291.13
width5.0

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDXUYFNEP100005111 @ $291.13
