Mean Well Power Supply, Ac-Dc, 15V, 23.2A Rohs Compliant: Yes - LRS-350-15

Authentic Taiwan LRS-350-15 350W 15V 23.2A meanwell power switch ultra-thin 3 years warranty

Model: &nbsp;LRS-350-15 &lt;/br&gt;<br /> Input: 85 to 264V AC &lt;/br&gt;<br /> Output: 15V 23.2A &lt;/br&gt;<br /> Size: 215x115x30mm &nbsp;(L * W * H) &lt;/br&gt;<br /> 100% load burn-in test &lt;/br&gt;<br /> Small, high power den &lt;/br&gt;

<p><b>Features:</b></p> <p> No load power consumption <0.5W for 150W; <0.75W for 200W/350W</p> <p>AC input selectable by switch</p> <p>Withstand 300VAC surge input for 5 seconds</p> <p>Ultra compact and 1U low profile</p> <p>Withstand 5G vibration test</p> <p>High operating temperature up to 70oC</p> <p>Protections: Short circuit / Overload / Over voltage / Over temp.</p> <p>Cooling by free air convection (150W/200W); forced air cooling by built-in DC fan (350W)</p> <p>Compliance to IEC/EN60335-1(PD3) and IEC/EN61558-1,-2-16 for household appliances (150W)</p> <p>Operating altitude up to 5000 meters</p> <p>LED indicator for power on</p> <p>High efficiency, long life and high reliability</p> <p>Low cost</p> <p>3 years warranty</p> <p><b>General Specification (Please refer to images below for detailed datasheet)</b></p> <p>AC input voltage range:115 / 230VAC by switch</p> <p>AC inrush current (max.):Cold start, 60A at 230VAC</p> <p>DC adjustment range:±10% by potentiometer</p> <p>Overload protection Range:110%~140%</p> <p>Overload protection Type:Hiccup mode, auto-recovery</p> <p>Over voltage protection Range:115%~145% rated output voltage</p> <p>Over voltage protection Type:Shut down o/p voltage, re-power on to recover</p> <p>Withstand voltage:I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC</p> <p>Working temperature:-25~+70°C (refer to output derating curve)</p> <p>Safety standards:UL60950-1 approved</p> <p>EMC standards:Design refer to EN55022 class A</p> <p>Connection:9P/9.5mm pitch terminal block</p> <p>Dimension (LxWxH):215x 115x 30</p>

The LRS-350 series is a 350W single-gang output enclosed power supply with a 30mm low-profile design and 115VAC or 230VAC input (selectable by switch). (selectable by switch), the whole series offers 3.3V, 4.2V, 5V, 12V, 15V, 24V, 36V and 48V  In addition to the 89% efficiency, the built-in long-life fan enables the LRS-350 to operate at full load over a temperature range of -25°C to +70°C. The LRS-350 is also available in a wide range of colors and sizes.

Applications : Industrial automation machinery Industrial control system Mechanical and electrical equipment Electronic instruments, equipments or apparatus
