MEAN WELL SP-100-13.5 | Power supply: switched-mode; for building in,modular; 101.25W

MEAN WELL . SP-100-13.5

Gallery

Attributes

Brand name, Manufacturer name, Attribute00MEAN WELL
Manufacturer, BrandMEAN WELL Mean Well
Attribute01switched-mode
Attribute02for building in,
Attribute03101.25W
Attribute0413.5V DC
Attribute057.5A
Attribute06, atoms, moq, multiple, Case, Item_package_quantity, PackageQuantity1
Attribute07179x99x45mm
Attribute08-10...60?C
Attribute09terminal block
Attribute10anti-overload OPP,
Attribute1183%
Attribute12SP-100
Attribute13915A
Attribute14active PFC
Attribute15DRL-02,
Attribute1612.8...14.9V DC
AttributeKey00Manufacturer
AttributeKey01Type of power supply
AttributeKey02Kind of power supply
AttributeKey03Power
AttributeKey04Output voltage
AttributeKey05Output current
AttributeKey06Number of outputs
AttributeKey07Body dimensions
AttributeKey08Operating temperature
AttributeKey09Electrical connection
AttributeKey10Protection
AttributeKey11Efficiency
AttributeKey12Manufacturer series
AttributeKey13Kind of case
AttributeKey14Additional functions
AttributeKey15Related items
AttributeKey16Output voltage range
CategoryL1Power Sources
CategoryL2Power Supplies
CategoryL3Built-in Power Supplies
Extra Product NameMEAN WELL SP-100-13.5 | Power supply: switched-mode; for building in,modular; 101.25W
jsonUrlData9da75a30f6bb36000995f59052479286.
jsonUrlData250fc4b986d765b68c331
keywordsMEAN WELL, SP-100-13.5
MPN, SKU, Part Number, Model, ModelNumber, Model_number, Mpns, PartNumber, Part_numberSP-100-13.5
qtyInStock0
snippetMEAN WELL SP-100-13.5 | Power supply: switched-mode; for building in,modular; 101.25
UPC, EAN, EANList, UPCList647336001624
Product Group, ProductGroupSpeakers
ASIN, AsinB077RC3HGN
AdultProduct, Autographed, Batteries_required, Memorabilia, TradeInEligibleFalse
Binding, CatElectronics
Bullet_pointApprox. Wattage: 100W Output Voltage: 13.5V Protections: Short circuit / Overload / Over voltage Warranty: 3 Years Warranty
CatId172282
CatTree172282 172456 493964 541966
ClassificationId764572
Cooling_methodAir
DisplayNameUninterruptible Power Supply (UPS)
Externally_assigned_product_identifier, Identifier0647336001624 647336001624
FeatureOutput Voltage: 13.5V
FetchTime1537912690 1567849708 1570453872 1672930904 1699541710
Height1.77165 1.7716500 1128 376 45.0 56 75
IdentifierTypeEAN UPC
ItemClassificationBASE_PRODUCT
ItemName, Item_nameMeanwell SP-100-13.5 Power Supply - 100W 13.5V 7.5A - PFC
Item_type_keyworduninterrupted-power-supplies
Item_weight1.39
KeywordPS-PTFEB-13
Label, Man, Publisher, StudioMean Well
Length179.0 7.04723 7.0472300
Linkhttps://m.media-amazon.com/images/I/413O+gas-nL._SL75_.jpg https://m.media-amazon.com/images/I/413O+gas-nL.jpg https://m.media-amazon.com/images/I/51jUBYciqNL.jpg https://www.amazon.com/gp/bestsellers/pc/764572
Marketplace_idATVPDKIKX0DER
Output_wattage, Wattage100.0
ProductTypeSYSTEM_POWER_DEVICE
ProductTypeNamePOWER_SUPPLIES_OR_PROTECTION
Product_description<p><b>Features:</b></p> <p>Universal AC input / Full range</p> <p>Built-in active PFC function</p> <p>Protections: Short circuit / Overload / Over voltage</p> <p>Cooling by free air convection</p> <p>Optional remote ON/OFF control</p> <p>100% full load burn-in test</p> <p>3 years warranty</p> <p><b>General Specification (Please refer to images below for detailed datasheet)</b></p> <p>AC input voltage range:85~264VAC; 120~370VDC</p> <p>AC inrush current (max.):Cold start, 35A at 230VAC</p> <p>DC adjustment range:-5%~+10% rated output voltage</p> <p>Overload protection Range:105%~150%</p> <p>Overload protection Type:Constant current limiting, auto-recovery</p> <p>Over voltage protection Range:110%~135%</p> <p>Over voltage protection Type:Shut off, AC recycle to re-start</p> <p>Withstand voltage:I/P-O/P: 3kVAC, I/P-FG: 1.5kVAC, O/P-FG: 0.5kVAC, 1 minute</p> <p>Working temperature:-10~+60°C</p> <p>Safety standards:UL60950-1, TUV EN60950-1,</p> <p>EMC standards:EN55022 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3</p> <p>Connection:7P / 9.5mm pitch terminal block with cover</p> <p>Dimension (LxWxH):179x 99x 45</p> <p>Case No.:915A</p> <p>Packing:20pcs/14.3kg</p>
Product_site_launch_date2017-11-26T08:44:46.899Z
Rank2200
RunningTime, Runtime1.0
SkuMEAN WELL SP-100-13.5 MEAN WELL SP-100-5
StrippedMpnsSP10013.5
TitleComputer Uninterruptible Power Supply Units Meanwell SP-100-13.5 Power Supply - 100W 13.5V 7.5A - PFC
Typeean upc
URLhttp://ecx.images-amazon.com/images/I/51uwEmaBLSL._SL75_.jpg https://m.media-amazon.com/images/I/413O+gas-nL._SL75_.jpg
Unitinches millimeters minutes pounds watts
Unitsinches minutes pixels pounds
VariantMAIN
WebsiteDisplayGroupce_display_on_website
WebsiteDisplayGroupNameCE
Weight0.000625 1.39 1.5432358340
Width1500 3.89763 3.8976300 500 75 99.0

Distributor offers

SellerSKUMOQIn stockMultiplePrices
TMESP-100-13.511
electricautomationnetwork.comSP-100-13.511
Jameco69347611
Digi-Key770688011
RS Delivers678-3805111 @ $65.28, 5 @ $62.01, 10 @ $58.76, 25 @ $55.49, 50 @ $52.23
Onlinecomponents.comSP-100-13.5111 @ $39.10, 2 @ $37.88, 11 @ $35.38, 21 @ $33.13

Related on Amazon

As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.

Meanwell SP-100-13.5 Power Supply - 100W 13.5V 7.5A - PFC
Brand: Mean Well
<p><b>Features:</b></p> <p>Universal AC input / Full range</p> <p>Built-in active PFC function</p> <p>Protections: Short circuit / Overload / Over voltage</p> <p>Cooling by free air convection</p> <p>Optional remote ON/OFF control</p> <p>100% full load burn-in test</p> <p>3 years warranty</p> <p><b>General Specification (Please refer to images below for detailed datasheet)</b></p> <p>AC input voltage range:85~264VAC; 120~370VDC</p> <p>AC inrush current (max.):Cold start, 35A at 230VAC</p> <p>DC adjustment range:-5%~+10% rated output voltage</p> <p>Overload protection Range:105%~150%</p> <p>Overload protection Type:Constant current limiting, auto-recovery</p> <p>Over voltage protection Range:110%~135%</p> <p>Over voltage protection Type:Shut off, AC recycle to re-start</p> <p>Withstand voltage:I/P-O/P: 3kVAC, I/P-FG: 1.5kVAC, O/P-FG: 0.5kVAC, 1 minute</p> <p>Working temperature:-10~+60°C</p> <p>Safety standards:UL60950-1, TUV EN60950-1,</p> <p>EMC standards:EN55022 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3</p> <p>Connection:7P / 9.5mm pitch terminal block with cover</p> <p>Dimension (LxWxH):179x 99x 45</p> <p>Case No.:915A</p> <p>Packing:20pcs/14.3kg</p>
Details
  • Output Voltage: 13.5V
  • Approx. Wattage: 100W
  • Protections: Short circuit / Overload / Over voltage
  • Warranty: 3 Years Warranty
Listing
BindingElectronics
Product groupSpeakers
Product typePOWER_SUPPLIES_OR_PROTECTION
ModelSP-100-13.5
Part numberSP-100-13.5
LabelMean Well
ManufacturerMean Well
Catalog
FeatureOutput Voltage: 13.5V
CategoryElectronics
MPNSP-100-13.5
UPC647336001624
EAN647336001624
Product groupSpeakers
Product typePOWER_SUPPLIES_OR_PROTECTION
ManufacturerMean Well
