Safety switch, Telemecanique Safety switches XCS, metal XCSLF, 2NC+4 NO, slow break, 3 entries tapped M20, 120 V | Mayer Electric

SQUARE D . SQDXCSLF3535332

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerSQUARE D
Attribute00120 V - 15...10 %
Attribute011 NC + 2 NO
Attribute02Telemecanique Safety switches XCS
Attribute033 entries tapped M20 x 1.5
Attribute04spring terminal 1 x 1.5 mm? flexible or solid cable || spring terminal 2 x 0.5 mm? flexible cables with 13 mm bared ends
Attribute05with interlocking, locking by solenoid
Attribute06slow-break, break before make
Attribute07for actuator withdrawn 1 LED (orange) || for actuator inserted and locked 1 LED (green)
Attribute081 NC + 2 NO slow-break, break before make)
Attribute09locking on de-energisation and unlocking on energisation of solenoid
Attribute10safety switch
Attribute11120 V
Attribute12XCSLF
Attribute137-13 mm
Attribute14metal
Attribute15slim
Attribute163
Attribute17key operated turret head
Attribute1818 months
Attribute1910 mA at 20 ?C
Attribute20205-205 mm
Attribute2110 cyc/mn for maximum durability
Attribute22300 VUL 508 || 300 VCSA C22.2 No 14 || 250 V 3)EN/IEC 60947-1
Attribute234 A cartridge fuse gG (gl) || 6 A fast blow
Attribute24with NC contact
Attribute25, moq, multiple, tierMinQty11
Attribute260.01 m/s
Attribute270.55 A 24 V, DC-13, R300 EN/IEC 60947-5-1 || 0.75 A 240 V, AC-15, C300 EN/IEC 60947-5-1
Attribute2820 N
Attribute291000000 cycles
Attribute300.5 m/s
Attribute31, Attribute37zamak
Attribute324 A
Attribute33B10d = 5500000 value given for a life time of 20 years limited by mechanical or contact wear
Attribute34AC/DC
Attribute3544 mm
Attribute3651 mm
Attribute38AC
Attribute3917 V
Attribute403000 N
Attribute419.6 J against the partition || 6.4 J without partition
Attribute421.1 kg
Attribute434 kV EN/IEC 60947-5-1
Attribute4450/60 Hz
Attribute45can reach category 4 with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach PL = e with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach SIL 3 EN/IEC 61508
Attribute46ENVEOLI110903EN
Attribute47, Attribute48Yes
Attribute49ENVPEP110916EN
Attribute50Green Premium product
Attribute51Pro-active compliance (Product out of EU RoHS legal scope)
Attribute52Reference contains Substances of Very High Concern above the threshold
Attribute53Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Attribute54UL || T?V || CSA
Attribute55-25-60 ?C
Attribute56-40-70 ?C
Attribute57UL 508 || EN 1088/ISO 14119 || EN/IEC 60204-1 || EN/IEC 60947-5-1 || EN/ISO 13849-1 || CSA C22.2 No 14 || EN/IEC 62061
Attribute58class I EN/IEC 61140
Attribute5910 gn 11 ms IEC 60068-2-27
Attribute605 gn 10-500 Hz)IEC 60068-2-6
Attribute61TC
Attribute62IP66 conforming to EN/IEC 60529 and EN/IEC 60947-5-1 || IP67
AttributeKey00[Us] Rated Supply Voltage
AttributeKey01Contacts Type And Composition
AttributeKey02Range Of Product
AttributeKey03Cable Entry
AttributeKey04Electrical Connection
AttributeKey05Locking Options Description
AttributeKey06Contact Operation
AttributeKey07Local Signalling
AttributeKey08Solenoid Contacts Type And Composition
AttributeKey09Electromagnet Interlocking
AttributeKey10Product Or Component Type
AttributeKey11Signalling Circuit Voltage
AttributeKey12Component Name
AttributeKey13Cable Outer Diameter
AttributeKey14Material
AttributeKey15Design
AttributeKey16Number Of Poles
AttributeKey17Head Type
AttributeKey18Warranty
AttributeKey19Minimum Switching Current
AttributeKey20, height_AttribHeight
AttributeKey21Maximum Operating Rate
AttributeKey22[Ui] Rated Insulation Voltage
AttributeKey23Short-Circuit Protection
AttributeKey24Positive Opening
AttributeKey25Load Factor
AttributeKey26Minimum Actuation Speed
AttributeKey27[Ie] Rated Operational Current
AttributeKey28Minimum Actuator Force For Extraction
AttributeKey29Mechanical Durability
AttributeKey30Maximum Actuation Speed
AttributeKey31Body Material
AttributeKey32[Ithe] Conventional Enclosed Thermal Current
AttributeKey33Safety Reliability Data
AttributeKey34Supply Voltage Type
AttributeKey35, width_AttribWidth
AttributeKey36, length_AttribDepth
AttributeKey37Head Material
AttributeKey38Signalling Circuit Type
AttributeKey39Minimum Switching Voltage
AttributeKey40Maximum Actuator Forcible Withdrawal Rtc
AttributeKey41Resistance To Mechanical Impact
AttributeKey42, Weight_AttribNet Weight
AttributeKey43[Uimp] Rated Impulse Withstand Voltage
AttributeKey44Supply Frequency
AttributeKey45Safety Level
AttributeKey46Circularity Profile
AttributeKey47Rohs Exemption Information
AttributeKey48Mercury Free
AttributeKey49Environmental Disclosure
AttributeKey50Sustainable Offer Status
AttributeKey51Eu Rohs Directive
AttributeKey52Reach Regulation
AttributeKey53California Proposition 65 : WARNING: This product can expose you to chemicals including
AttributeKey54Product Certifications
AttributeKey55Ambient Air Temperature For Operation
AttributeKey56Ambient Air Temperature For Storage
AttributeKey57Standards
AttributeKey58Electrical Shock Protection Class
AttributeKey59Shock Resistance
AttributeKey60Vibration Resistance
AttributeKey61Protective Treatment
AttributeKey62Ip Degree Of Protection
DimensionUnitmm
Extra Product NameSafety switch, Telemecanique Safety switches XCS, metal XCSLF, 2NC+4 NO, slow break, 3 entries tapped M20, 120 V | Mayer Electric
UPC3606489413354
Weight1.1
WeightUnitkg
depth, length51.0
height410.0
jsonUrlData/Product/SQUARE-D-Safety-switch-Telemecanique-Safety-switches-XCS-metal-XCSLF-2NC4-NO-slow-break-3-entries-tapped-M20-120-V-3606489413354
jsonUrlData235440024-b370-4bc6-8e8f-aeea00585160
MPN, SKUSQDXCSLF3535332
qtyInStock0
tierPrice1505.78
width44.0

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDXCSLF3535332111 @ $505.78
