Order AR410BP-C/C by AR North America 106 Max GPM Diaphragm Pump, 290 Max PSI - US Mega Store

AR North America . AR410BP-C/C

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerAR North America
CategoryL1Plumbing
CategoryL2Pumps
CategoryL3Diaphragm
CategoryL4AR North America AR410BP-C/C
ConditionNEW
Extra Product NameOrder AR410BP-C/C by AR North America 106 Max GPM Diaphragm Pump, 290 Max PSI - US Mega Store
moq, multiple, tierMinQty11
MPN, SKUAR410BP-C/C
qtyInStockContact Us
snippet<p><strong>106 Max GPM Diaphragm Pump, 290 Max PSI </strong> </p> <p>Semi-hydraulic six-diaphragm pump, for use in low pressure systems. Parts in contact with pumped liquids in plastic-coated aluminium Rilsan and AISI 303/304. Diaphragms in NBR. Seals in NBR. Fitted with air-hydraulic damper for smoother operation and less hammer effect in the delivery circuit. Die-cast casing with oilimmersed mechanism and clear plastic tank for visual level checking. Remote level monitoring sensor on request. Remote oil tank installation kit available on request. Oil drainage stopper. Pistons with ring for a more efficient &ldquo;oil cushion&rdquo; system to protect the diaphragm. New-design diaphragm cut-out system to prevent contact tearing even in heavy-duty operating conditions. Spherical sector profile valves for lower flow resistance and improved volumetric efficiency. Rugged feet secured to pump casing. Geomet stainless steel finish metal fasteners. Stopper for drainage of liquid from the circuit before storage over winter. Complete with drive shaft guard. Available pulley fixtures, flanges for hydraulic motors and hydraulic pumps for overgears. Kit for combining two pumps to form a modular unit to supply the sprayer&rsquo;s various uses. </p>
tierPrice14349

Distributor offers

SellerSKUMOQIn stockMultiplePrices
usmegastore.comAR410BP-C/C1Contact Us11 @ $4349.00
MegadepotAR410BP-C/C111 @ $4349.00
heavydutydepot.comAR410BP-C/C111 @ $4349.00
