Mean Well Dc-Dc Converter, 5V, 40A - SD-200D-5
Gallery
Attributes
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Newark | 44AC7475 | 1 | 1 | 1 | 1 @ $26.39, 10 @ $26.39, 25 @ $26.39, 50 @ $26.39, 100 @ $26.39, 250 @ $26.39 |
 powersupplymall.com | SD-200D-5 | 1 | 8 | 1 | 1 @ $81.40 |
 peaktopeakpower.com | SD-200D-5 | 1 | -2 | 1 | 1 @ $70.90 |
| G905827464 | 1 | 1 | 1 @ $86.99 | ||
| Waldom | MEAN WELL SD-200D-5 | 1 | 4 | 1 | 1 @ $55.20 |
| electricautomationnetwork.com | SD-200D-5 | 1 | 1 | 1 @ $104.68 | |
 Digi-Key | 7706505 | 1 | 1 | 1 @ $110.59, 10 @ $108.83, 25 @ $101.81, 50 @ $98.30, 100 @ $93.39, 250 @ $92.74 | |
| Jameco | 2107143 | 1 | 1 | ||
| Allied Electronics | 71753971 | 1 | 1 | ||
 TME | SD-200D-5 | 1 | 1 | ||
 AmazonSC | B06X9NCJQ3 | 1 | -2 | 1 | 1 @ $113.23 |
 Onlinecomponents.com | SD-200D-5 | 1 | 2 | 1 | 1 @ $70.90, 10 @ $66.04, 20 @ $62.74, 50 @ $59.61 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
SD-200D-5 DC/DC Power Supply Single-Out 5V 40A 200W 9-Pin
Brand: MEAN WELL
DC DC Power Supply Single-OUT 5V 40A 200W 9-Pin
Listing
| Binding | Misc. |
|---|---|
| Product group | PC Accessory |
| Product type | SYSTEM_POWER_DEVICE |
| Part number | SD-200D-5 |
| Label | Mean Well |
| Manufacturer | Mean Well |
Catalog
| Category | Electronics |
|---|---|
| MPN | SD-200D-5 |
| Product group | BISS |
| Product type | TOOLS |
| Manufacturer | Mean Well |
Mean Well Dc-Dc Converter, 5V, 40A - SD-200D-5
Brand: MEAN WELL
DC-DC CONVERTER, 5V, 40A; No. of Outputs:1 Output; Output Power Max:200W; Output Voltage - Output 1:5V; Output Current - Output 1:40A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output RoHS Compliant: Yes
Details
- <b>Price For:</b> Each <b>No. of Outputs</b>: 1 Output <b>Output Power Max</b>: 200W <b>Output Voltage - Output 1</b>: 5V <b>Output Current - Output 1</b>: 40A <b>Output Voltage - Output 2</b>: - <b>Output Current - Output 2</b>: - <b>Output Voltage - Output 3</b>: - <b>Output Current - Output 3</b>: - <b>Product Range</b>: SD-200 Series <b>Input Voltage DC Min</b>: 72V <b>Input Voltage DC Max</b>: 144V <b>DC / DC Converter Mounting</b>: Panel
- <b>DC / DC Converter Output Type</b>: Fixed
Listing
| Binding | Electronics |
|---|---|
| Product group | BISS Basic |
| Product type | POWER_CONVERTER |
| Model | SD-200D-5 |
| Part number | SD-200D-5 |
| Items per pack | 1 |
| Label | Mean Well |
| Manufacturer | Mean Well |
Catalog
| Feature | 2:1 wide input range |
|---|---|
| Category | Electronics |
| MPN | SD-200D-5 |
| EAN | 6282234037975 |
| Product group | Speakers |
| Product type | POWER_SUPPLIES_OR_PROTECTION |
| Manufacturer | MEAN WELL |
MEAN WELL MW SD-200D-5 5V 34A Enclosed Single Output DC-DC Converter
Brand: MEAN WELL
<b>Features</b><br>2:1 wide input range<br>1500VAC I/O isolation<br>Cooling by free air convection<br>Protections: Short circuit / Over load / Over voltage<br>Built-in EMI filter, low ripple noise<br>100% full load burn-in test<br>Low cost, high reliability<br>2 years warranty
Details
- 2:1 wide input range
- 1500VAC I/O isolation
- Built-in EMI filter, low ripple noise
- 100% full load burn-in test
- 2 years warranty
Listing
| Product group | Speakers |
|---|---|
| Product type | LAB_SUPPLY |
| Model | SD-200D-5 |
| Part number | SD-200D-5 |
| Label | MEAN WELL |
| Manufacturer | MEAN WELL |
Catalog
| Feature | 2:1 wide input range |
|---|---|
| Category | Electronics |
| MPN | SD-200D-5 |
| EAN | 6160204065862 |
| Product group | Speakers |
| Product type | LAB_SUPPLY |
| Manufacturer | MEAN WELL |
Meanwell SD-200D-5 DC-DC Converter - 200W - 72~144V in 5V Out
Brand: Mean Well
<p><b>Features:</b></p> <p>2:1 wide input range</p> <p>Protections:Short circuit / Overload / Over voltage / Over temperature</p> <p>1500VAC I/O isolation</p> <p>Cooling by free air convection</p> <p>100% full load burn-in test</p> <p>24V and 48V input voltage design refer to LVD</p> <p>2 years warranty</p> <p></p> <p><b>General Specification:</b></p> <p>AC input voltage range: B: 19~36VDC ;C: 36~72VDC ; D: 72~144VDC</p> <p>AC inrush current (Typ.): C: 45A~48VDC ;D: 45A~96VDC</p> <p>DC adjustment range: 5V: 4.5~5.5VDC, 12V: 11~16VDC ,24V: 23~30VDC ,48V: 43~53VDC</p> <p>Over voltage protection:5V: 5.75~6.75V, 12V: 16.8~20V ,24V: 31.5~37.5V ,48V: 53~65V, Protection type : Shut down o/p voltage, re-power on to recover</p> <p>Overload protection: 105~135% rated output power , Protection type: shut down o/p voltage , re-power on to recover</p> <p>Over temperature protection: Shut down o/p voltage, recovers automatically after temperature goes down</p> <p>Withstand voltage:I/P-O/P: 1.5KVAC ,I/P-F/G: 2KVAC ,O/P-F/G: 0.5KVAC</p> <p>Working temperature: -20~ +60ºC (Refer to "Derating Curve")</p> <p>Safety standards:UL60950-1 approved(for SD-200C-24 type only),IEC60950-1 CB approved by TUV(for D type only), EAC TP TC 004 approved</p> <p>EMC standards: Compliance to EN55032 (CISPR32) Class B, Compliance to EN61000-4-2,3,4,6,8, light industry level, criteria A ,EAC TP TC 020</p> <p>Isolation resistance:I/P-O/P,I/P-F/G,O/P-F/G: 100M Ohms/500VDC/25ºC/70% RH</p> <p>Dimension (LxWxH) (mm):215x 115x 50</p>
Details
- Output Voltage: 5V
- Approx. Wattage: 200W
- Mechanical Form: Metal
- Warranty: 2 Years Warranty
Listing
| Product group | BISS Basic |
|---|---|
| Product type | TRANSFORMER |
| Part number | SD-200D-5 |
| Label | Mean Well |
| Manufacturer | Mean Well |
