Jameco Kitpro . CJKIT-20453

<h1>Water Level Control Kit</h1> <p> Design a simple water controller in which electrodes are required to sense high and low water levels in a tank. Whenever water level falls below the low level electrode, water pump is started and it stops once water level touches high level electrode. There is a third electrode which is used to detect water level from the pump suction port tank. If this electrode does not sense water then pump is not allowed to run to protect it from burning. Power is obtained from the AC line through an AC-to-AC Wall transformer. The control electronics and relay work from 12Vdc voltage regulator. Check out what others are saying about the Water Level Control project build! </p><br><br> <p><b>Please note: </b>Due to inventory packaging methods, you may receive extra components for some products.</p><h3>You Will Need</h3><ul> <li>Soldering iron and solder <li>AC to AC Wall adaptor (Jameco P/N: 2076543) <li>100' 24 AWG wire(Jameco P/N: 734411) <li>Small flat screwdriver <li>Wire stripper and cutter <li>Needle nose pliers</ul> <h3>Kit Includes:</h3> <table border="1" bordercolor="#333333"> <tr> <td width="70" style="padding-left:6px" bgcolor="#CCCCCC"><b>Part No.</b></td> <td width="30" style="padding-left:6px" bgcolor="#CCCCCC"><b><center>Qty.</center></b></td> <td width="350" style="padding-left:6px" bgcolor="#CCCCCC"><b>Description</b></td> </tr> <tr> <td width="70" style="padding-left:6px">12562</td> <td width="30" style="padding-left:6px"><center>1</center></td> <td width="350" style="padding-left:6px"> IC,CD4001</td> </tr> <tr> <td width="70" style="padding-left:6px">30496</td> <td width="30" style="padding-left:6px"><center>10</center></td> <td width="350" style="padding-left:6px"> CAPACITOR, 220uF,25V,20%,85C </td> </tr> <tr> <td width="70" style="padding-left:6px">35991</td> <td width="30" style="padding-left:6px"><center>10</center></td> <td width="350" style="padding-left:6px"> DIODE, 1N4004,1A </td> </tr> <tr> <td width="70" style="padd
