Hatch Transformer 150W Metal Halide Electronic Ballast 120V Side Leads

Hatch Lighting Standard series Electronic HID ballast has durable metal housing construction and pulse start type. It operates at a power rating of 164 Watts, voltage rating of 120 Volts AC, current rating of 1.37 Amps, temperature rating of 80 deg C and frequency rating of 50/60 Hz. This thermally protected ballast features excellent hot lamp restrike characteristic and U - standard case style. It supports 150-Watt ceramic metal halide lamp that provides wide range of lumen output. This transie

<h4>Input</h4><ul><li>Lamp Operating Frequency: 165Hz Square Wave</li><li>Lamp Current C.F.; &lt;1.3</li></ul><h4>Ordering information</h4><ul><li>Standard Case Quantity: 50 Units</li><li>Unit Weight/Case Weight: 0.88 lbs/46.5 lbs</li></ul><h4>Product features</h4><ul><li>&nbsp;Thermal protection</li><li>Approved for recessed use</li><li>Micro Processor Controlled</li><li>Safety Shut Down Features</li><li>Superior Hot Lamp Restrike</li></ul><h4>Characteristic</h4><ul><li>Sound Rated: A</li><li>Minimum Starting Temperature: -30&deg;C</li><li>Maximum Case Temperature: 80&deg;C</li><li>Complies with FCC Part 18 (Class B) Consumer limits</li><li>Up to 5 Year Warranty</li><li>Transient Protection</li><li>Lamp end-of-life protected</li><li>Short Circuit Protection</li><li>Open Circuit/No Lamp/ Hot Lamp Shutdown, </li></ul><h4>Retry and Ignition Failure Protection: </h4><p>Ignition failure shutdown in 5 seconds followed by multiple timed restrikes with lamp ignition or timed shutdown until power is reset (restrike timing is lamp wattage dependent)</p>

This Standard case 150W, 120V ballast with side leads and mounting feet provide easy installation, even if remote mounted. It features superior line and lamp voltage regulation due to advanced microprocessor control and superior reliability with patented Half Bridge technology.
