PILZ . 570000-PILZ

Pilz Mechanical Safety Switches, PSENMECH Series Item# 570000 - Door Interlock Switch w/Actuator, PSEN me1S/1AS, PSEN Mech, M20 Cable Entry PSENMECH Series Information Mechanical Operation Radius or Standard Actuators Guard Locking Types Available IP65/IP67 Protection UL; cUL Approvals PSENmech mechanical safety switches are suitable for safe monitoring of a movable guard. They are triggered if the guards are opened, and the hazardous machine movement is stopped via a Pilz evaluation device. Using increased extraction force on the actuator, PSENmech safety switches prevent the safety gate from being opened unintentionally. They comply with the standard EN 1088 (protection against defeat) due to their coded actuators. PSENmech safety switches with guard locking ensure that the safety gate is interlocked (guard locking) until the hazardous production process is complete. They can also prevent production from being interrupted as a result of unauthorized access. Robust Design for Long Service Life Suitable for a Variety of Applications Specifications Item Number: 570000 UPC: 4046548002911 Brand: Pilz Series: PSENMECH Guard Locking Type: Current Unlocks (Closed Circuit) Contacts: 2NO/2NC Thermal Current Rating: 2.5 Amps Operating Voltage: 24 VAC;24 VDC Holding Force: 1,500 Newtons Extraction Force: 27 Newtons Auxiliary Release: Yes Connection Type: Cage Clamp Terminals Adjustable Actuator Head: Yes Protection Rating: IP67 Approvals: UL;cUL Picture No.: PILZ_SWIT_PSEN-ME1-S H x W x D: 7.24 in x 1.67 in x 2.01 in Net Weight: 11.8873 OZ Gross Weight: 14.674 OZ
