Mean Well Power Supply, Ac-Dc, 24V, 5A - WDR-120-24

WDR-120-24 Mean Well Power Supply

MW Mean Well WDR-120-24 24V 5A 120W Single Output Industrial DIN Rail Power Supply

<p><b>Features:</b></p> <p>Single and two phase wide input range 180~550VAC</p> <p>Cooling by free air convection</p> <p>Built-in constant current limiting circuit</p> <p>Can be installed on DIN rail TS-35 / 7.5 or 15</p> <p>UL508(industrial control equipment) approved</p> <p>EN61000-6-2(EN50082-2) industrial immunity level</p> <p>Built-in DC OK relay contact</p> <p>100% full load burn-in test</p> <p>3 years warranty</p> <p><b>General Specification (Please refer to images below for detailed datasheet)</b></p> <p>AC input voltage range:180~550VAC(single and two phase); 254~780VDC</p> <p>AC input current:0.55A / 400VAC, 1.2A / 230VAC</p> <p>AC inrush current (max.):Cold start, 50A at 400VAC</p> <p>DC adjustment range:12V: 12~15V, 24V: 24~29V, 48V: 48~58V</p> <p>Overload protection:105%~130% rated output power, constant current limiting, auto-recovery</p> <p>Over voltage protection Range :16~18V for 12V model (only for WDR-120), 29~33V for 24V model, 56~65V for 48V model</p> <p>Over voltage protection Type:Shut down o/p voltage, auto-recovery</p> <p>Setup, rise, hold up time:2000ms, 70ms, 10ms at full load and 230VAC; 2000ms, 70ms, 50ms at full load and 400VAC</p> <p>Over temp. Protection:Shut down output voltage, recovers automatically after temperature goes down</p> <p>Withstand voltage:I/P-O/P:3kVAC, I/P-FG:1.5kVAC, O/P-FG:0.5kVAC, O/P-DC OK:0.5kVAC, 1 minute</p> <p>Working temperature:-25~+70°C (refer to output derating curve)</p> <p>DC OK signal:Relay Contact</p> <p>Leakage current:<3.5mA at 530VAC</p> <p>Vibration:10~500Hz, 2G 10 minutes / 1 cycle, period of 60 minutes each along X, Y, Z axes</p> <p>Safety standards:UL508 approved ; IEC60950-1 CB approved by SIQ ; Design refer to GL</p> <p>EMC standards:EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2), EN61204-3, heavy industry level</p> <p>Connection:I/P: 3 poles, O/P: 4 poles screw DIN terminal</p> <p>Dimension (LxWxH)(mm):40x125.2x113.5</p>

Welcome,you can buy all of the MEAN WELL power supplies in <strong>Power home</strong>.<br /> <br /> We are MEAN WELL agents,there are more than 5000 kinds of products in stock,ensure rapid delivery,price advantage,if you are business customer or purchase <strong>more than 20 pcs</strong>,please contact us for a more favorable price!<br /> <br /> Note:too cheap products may be imitation or defective products,usually a few months later may be broken,the original product can be used for 5 years or more,the power will not burn the equipment,this is the real bargain!

This item will ship WDR-120-24*1pcs,enjoy shopping and best wishes!

<b>Features</b><br>Single and two phase wide input range 180~550VAC<br>Built-in active PFC function (WDR-240/480)<br>Protections: Short circuit / Overload / Over voltage / Over temperature<br>Cooling by free air convection<br>Built-in constant current limiting circuit<br>Can be installed on DIN rail TS-35 / 7.5 or 15<br>UL508(industrial control equipment) approved<br>EN61000-6-2(EN50082-2) industrial immunity level<br>Built-in DC OK relay contact<br>100% full load burn-in test<br>3 years warranty<br>The transaction does not include any Import Tax / Duty / VAT / Brokerage Fees / Handling Fees. For more information about the tax rate, please check with local custom department before purchases. If you reject the package due to any charged tax or duty, we reserve the right to charge ALL shipping cost and 5% (of total price) handling fee. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. We do not responsible for any custom duty or import tax. Please check with your country's customs office to determine what these additional costs will be prior to buying. Sometime customs will inspect the parcel and sometime will not. If you have any special request, please kindly advise us once place order.
