MEAN WELL . EDR-120-12

EDR-120-12

The EDR-120 is an economical lightweight 120W rail type power supply that complies with German industry standard and is suitable for mounting on tracks TS-35/7.5 or TS-35/15, the body is designed to be 40mm wide in the cabinet and the entire range is available from 90Vac to 264Vac and complies with BS EN/EN610000000000-3. - 2 - 2 - EU EU EU Specified harmonic current specification

<b>Features</b><br>Universal AC input / Full range<br>Protections: Short circuit / Overload /Over voltage / Over temperature<br>Cooling by free air convection<br>Can be installed on DIN rail TS-35 / 7.5 or 15<br>UL508 (industrial control equipment) listed<br>EN61000-6-2 (EN50082-2) industrial immunity level<br>100% full load burn-in test<br>Low cost<br>2 years warranty<br>The transaction does not include any Import Tax / Duty / VAT / Brokerage Fees / Handling Fees. For more information about the tax rate, please check with local custom department before purchases. If you reject the package due to any charged tax or duty, we reserve the right to charge ALL shipping cost and 5% (of total price) handling fee. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. We do not responsible for any custom duty or import tax. Please check with your country's customs office to determine what these additional costs will be prior to buying. Sometime customs will inspect the parcel and sometime will not. If you have any special request, please kindly advise us once place order.

<p><b>Features:</b></p> <p>Universal AC input / Full range</p> <p>Protections: Short circuit / Overload / Over voltage / Over temperature</p> <p>Cooling by free air convection</p> <p>Can be installed on DIN rail TS35 / 7.5 or 15</p> <p>UL508 (industrial control equipment) listed</p> <p>EN61000-6-2 (EN50082-2) industrial immunity level</p> <p>100% full load burn-in test</p> <p>Low cost</p> <p>2 years warranty for EDR series</p> <p></p> <p><b>General Specification:</b></p> <p>AC input voltage range:90~264VAC; 127~370VDC</p> <p>AC inrush current (max.):Cold start, 35A at 230VAC</p> <p>DC adjustment range:12V: 12~14V, 24V: 24~28V, 48V: 48~55V</p> <p>Current adjustment range :10%~100% rated output current adjustable by 1~10Vdc, PWM signal or resistance</p> <p>Overload protection:105%~130% Constant current limiting, auto-recovery</p> <p>Over voltage protection:14V: 14~17V, 24V: 29~33V, 48V: 56~65V Shut down o/p voltage, re-power on to recover</p> <p>Over temperature protection:Shut down o/p voltage, re-power on to recover</p> <p>Withstand voltage:I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC</p> <p>Working temperature:-20~+60!aC (refer to output derating curve</p> <p>Safety standards:UL60950-1, TUV EN60950-1 approved</p> <p>EMC standards:EN55022 classA, EN61000-3-2(125W for EDR-150),3, <p>EN61000-4-2,3,4,5,6,8,11, EN61000-6-2(EN50082-2)</p> <p>Connection (screw DIN terminal):I/P: 3 poles, O/P: 4 poles</p> <p>Dimension (LxWxH) (mm) :40x 125.2x 113.5</p>

Welcome,you can buy all of the MEAN WELL power supplies in <strong>Power home</strong>.<br /> <br /> We are MEAN WELL agents,there are more than 5000 kinds of products in stock,ensure rapid delivery,price advantage,if you are business customer or purchase <strong>more than 20 pcs</strong>,please contact us for a more favorable price!<br /> <br /> Note:too cheap products may be imitation or defective products,usually a few months later may be broken,the original product can be used for 5 years or more,the power will not burn the equipment,this is the real bargain!

This item will ship EDR-120-12*1pcs,enjoy shopping and best wishes!

MEAN WELL EDR-120-12 Single Output Industrial DIN RAIL Power Supply

Features : Meanwell Power Supply 12VDC Universal AC input / Full range Protections: Short circuit / Overload / Over voltage / Over temperature Cooling by free air convection Can be installed on DIN rail TS-35 / 7.5 or 15 UL508 (industrial control equipment) approved EN61000-6-2(EN50082-2) industrial immunity level 100% full load burn-in test
