Midas . XL48

The XL48 integrates 8 XL4 type preamps with high-pass and low-pass filters in a 1U rack as well as 8 XL8 type A-D converters with a clock whose variation in the information transfer delay (jitter) is 1 ppm. The MIDAS XL48 has analog and digital outputs in AES/EBU and ADAT formats. The applications are numerous: recording, improving the performance of an existing console, "split" between an analog console and a digital console, etc.The remarkable points: 8 XL4 MIDAS preamps with on each channel high-cut filter, low-cut filter, phantom power, attenuator -20 dB, phase inverter8 8-segment LED bargraphs8 Analog converters Digital Worms MIDAS XL8 type 96 kHz 24-bit ultra-low latencyOperation at sample rates of 96, 88.2, 48, 44.1 kHz in 24 bitTemperature-compensating clock oscillator with ultra-low jitter (1 ppm) and Word Clock external sync options8 balanced inputs on bases XLR and Sub-Connector -D 25 points8 balanced analog outputs on D-Sub connector 25 points8 digital AES3 outputs on D-Sub connector 25 dots8 ADAT digital outputs on two TOSLINK connectors Word Clock input and output on BNC connector
