A.O. Smith B127 3/4 HP, 3450 RPM, 1 Speed, 230/115 Volts, 6.0/12.0 Amps, 1.5 Service Factor, 56J Frame, PSC, ODP Encl...

A.O. Smith Magnatek Centurion 1081 C-Face Threaded Shaft Full Rated 3/4 HP Pool Motor 115/230V # B127 Pool Pump Motor, Open Drip Proof, Permanent Split Capacitor, 3/4 HP, 3450 RPM, 56J NEMA Frame, 115/230 Voltage, 12.0/6.0 Full Load Amps, C-Face Mounting, Auto Thermal Protection, 1.5 Service Factor, Ambient 50 C, Insulation Class B, CWLE Rotation, Bearings Locked Double Sealed Ball on Shaft End, Efficiency Group Standard, Shaft Diameter 5/8 In, Shaft Length 2 9/16 In, Shaft Type Threaded, 303 Stainless Steel Shaft, Aluminum Flange, 60 Hz, Black Finish B-127

'Pool and Spa Pump Motor, Permanent Split Capacitor, Open Dripproof, 3/4 HP, 3450 Nameplate RPM, 56J Frame, CCWSE Motor Shaft Rotation, Voltage 115/230, 12.0/6.0 Full Load Amps, 1 Phase, 60 Hz, Face Motor Mounting Type, Ball Motor Bearings, Black, Motor Flange Material Aluminum, Shaft Threaded 7/16-20 UNF-2A RH 11/16 In. From End, Shaft Material 303 Stainless Steel, Motor Thermal Protection Auto, 1.50 Motor Service Factor, Ambient Temperature 50 Degrees C, Shaft Dia. 5/8 In.'

It is important to know that pool pump motors are not manufactured by the pump manufacturer; the motor will usually be manufactured by AO Smith, Magnetek or Centurion. Your pump's motor should have a label or faceplate on it which includes the information you need to replace your pump motor. The most important categories to note will be the horsepower (hp), motor frame (fr), voltage and service factor (sf). Some labels will provide you with a model number and it will usually be listed as CR or CAT. 3/4 Horsepower Full Rated Service Factor: 1.50 56J Frame Threaded Shaft 115/230 Volt 12.0/6.0 amps Capacitor Start Automatic Overload Protection Non-Reversible CCW Stainless Steel Shaft Can replace Hayward AX5060M Booster Pump Motor Cross Reference: SPX1607Z1BE, 1607Z-1-B4C, 1607Z-1-BC, SP-1607-Z1-B4C, SP-1607-Z1-BC, A0564200, C48K2N117A3, ST1072, 141968, 150235, 152559, 152565, 152617, 152769, 158131, 158534, 158575, 158595, 159811, 159982, 164276, 164302, 164520, 164564, 164582, 164808, 165111, 165384, 168097, 173763, 177018, 177024, 177072, 177169, 177459, 177499, 177842, 193631, B626, C1099, EB127, 1104355400, 15443, CT107, 7-164302-24, 10-177018-24, 10-164302-22, 8-177499-20, 8-164276-20, 8-164302-20, 8-164520-20, 8-168097-20, 8-173763-20, 8-164302-24, 7-193631-24, 8-164302-22, 8-168097-21, 8-173763-21, 5KC33MN2514X, 35B1187, MGT605098, 816430224, 16430200 When replacing your pool pump motor you should always replace the shaft seal as well. The shaft seal is a 2 part piece made of rubber, metal and ceramic and keeps water from entering the pump motor. It is located near the impeller at the end of the motor shaft. Shaft seals vary between pumps so be sure to order the appropriate shaft seal for your pump.?
